YR--320 5 Colors 5UV Flexo printer

Performance characteristics:

1, Adopt the ceramic anilox cylinder to transfer the ink.

2, Unwinding and rewinding are controlled by magnetic power brake, clutch, (Or controlled by auto tension controller of Mitsubishi of Japan).

3, Each printing unit adopts 3600 plate-adjustment.

4, IR dryer for each printing unit.(UV dryer is for option)

5, This machine has die-cutting station, and it can make printing and die cutting finished in one process.

6, The ink rollers will be separated from the printing roller, and keep running when the machine stopped.

7, The main motor adopts frequency conversion stepless timing motor.

8, The machine can finish material-feeding, printing, lighting, drying, laminating, die-cutting and rewinding in a lump.It is an ideal machine for printing note and top-grade adhesive label.

Main structure:

1.One Paste plate machine

2.One anilox roller for each group (LPI is optional, made in shanghai)

3.2 sets printing rollers

4.Printing both sides at the same time (with Reverse frame)

5.With the lamination station

6.One unwinding tension controller (Mitsubishi Japan)

7.One rewinding tension controller

8.magnetic power brake (made in wenzhou )

9.Frequency changer (Panasonic)

10.Mainframe: 2.2KW

Suitable material

Roll material such as paper, plastic, film, etc.

Printing colors

2-6 (colors )

Printing width

320mm

Printing length

142-320mm

Machine speed

70m/min

Printing speed

15-60m/min

Overprint precision

±0.1mm

Unwinding diameter

φ600mm

Rewinding diameter

φ500mm

Unwinding diameter of lamination

φ210mm
