Covered Line Wire AAC Overhead Cable
- Qingdao or Shanghai
- T/T
You May Like
-
Pvc Insulated Electrical Wire
-
Pvc Insulated Electrical Wire/building Wire/wire
-
450/750v Pvc Insulated Electrical Wire/ Building Wire
-
PVC Insulated Electrical Wire,building Wrie
-
0.6/1 kv Aluminum Conductor Pvc Insulated Overhead Cable Aerial Cable
-
Pvc Insulated Electrical Wire/building Wire/insulated Copper Wire
Product Details
| Place of Origin | Henan, China | Brand Name | Sanhe | |
| Model Number | Al/XLPE or PVC | Insulation Material | PVC | |
| Application | Overhead | Conductor Material | Aluminum |
Product Description
Covered Line Wire AAC overhead cable pvc insulated overhead cable
Covered Line Wires is used primarily for overhead secondary distribution lines. It is not an electrically insulated conductor and is treated as bare conductor when installed.
Construction
Conductors are aluminum alloy 1350-H19, 6201-181, or ACSR conductors, concentrically stranded and covered for weather proofing with polyethylene, high density polyethylene (HD) or crosslinked polyethylene (XLP).
Standards
ASTM B-230 - Aluminum 1350-H19 Wire for Electrical Purposes
ASTM B-231 - Concentric-Lay-Stranded Aluminum Conductors, Coated-Steel Reinforced (ACSR).
ASTM B-1248 - Polyethylene Plastics Molding and Extrusion Materials.
ASTM C-8.35 - Specifications for Weather-Resistant Polethylene-Covered Wire and Cable.
ICEAS-61-402
NEMA PUB NO. WC 5-1973 - Standards Publication Thermoplastic insulated Wire and Cable for the Transmission and Distribution of Electrical Energy.
Bitmap Item | Size AWG or MCM Bitmap | Strand Bitmap | Insulation Thickness Bitmap | Outside Diameter Bitmap | Rated Breaking Strength |
Apple | 6 | Solid | 30 mls | .222 Inches | 445 Lbs |
Pear | 4 | Solid | 30 mls | .264 Inches | 675 Lbs |
Apricot | 4 | 7/w | 30 mls | .285 Inches | 790 Lbs |
Peach | 2 | 7/w | 45 mls | .373 Inches | 1220 Lbs |
Quince | 1/0 | 7/w | 60 mls | .477 Inches | 1790 Lbs |
Orange | 2/0 | 7/w | 60 mls | .522 Inches | 2260 Lbs |
Fig | 3/0 | 7/w | 60 mls | .570 Inches | 2740 Lbs |
Olive | 4/0 | 7/w | 60 mls | .626 Inches | 3450 Lbs |
Pomegranate | 4/0 | 19/w | 60 mls | .632 Inches | 3620 Lbs |
Mulberry | 266.8 | 19/w | 60 mls | .692 Inches | 4470 Lbs |
Anona | 336.4 | 19/w | 60 mls | .766 Inches | 5535 Lbs |
Molles | 397.5 | 19/w | 75 mls | .852 Inches | 6400 Lbs |
Huckleberry | 477 | 37/w | 75 mls | .921 Inches | 7820 Lbs |
Paw Paw | 556.5 | 37/w | 75 mls | .982 Inches | 8950 Lbs |
Breadfruit | 636 | 61/w | 95 mls | 1.080 Inches | 10510 Lbs |
Persimmon | 795 | 61/w | 95 mls | 1.187 Inches | 12900 Lbs |
Grapefruit | 1033.5 | 61/w | 95 mls | 1.327 Inches |
16500 Lbs |
