HOT SALES FEP Insulation Stranded Tinned Copper Conductor Electrical Wire Cable UL1332 Style 10 12 14 16 18 20 22 24 26 28 30 AWG Gauge
Product Description
1. Nominal Voltage: 300V.
2. Temperature Range: -80°C to +200°C.
3. Conductor: Tinned Copper.
4. Insulation: FEP.
5. O.D.Allowance: ±0.10mm.
6. Available: Black-Brown-Red-Orange-Yellow-Green-Blue-Purple-Gray-White-Transparent-Yellow/green,etc.
| Conductor | Insulation | Electrical Characteristic | Packing | ||||
| AWG | Conductor construction NO.×mm | Diameter mm | Insulation Thickness mm | Over Diameter mm | Conductor Resistance 20°C ohm/km | Permissible ampacity 20°C -AMR | m/roll |
| 30 | 1×0.254 | 0.25 | 0.33 | 0.91 | 361 | 0.66 | 610 |
| 28 | 1×0.32 | 0.32 | 0.33 | 0.98 | 227 | 1.06 | 610 |
| 26 | 7×0.160 | 0.49 | 0.33 | 1.15 | 143 | 1.68 | 305 |
| 26 | 19×0.100 | 0.50 | 0.33 | 1.16 | 143 | 1.68 | 305 |
| 24 | 7×0.200 | 0.61 | 0.33 | 1.27 | 89.3 | 26.9 | 305 |
| 24 | 19×0.120 | 0.60 | 0.33 | 1.26 | 89.3 | 26.9 | 305 |
| 22 | 7×0.250 | 0.76 | 0.33 | 1.42 | 56.4 | 4.26 | 305 |
| 22 | 19×0.150 | 0.76 | 0.33 | 1.42 | 56.4 | 4.26 | 305 |
| 20 | 7×0.310 | 0.95 | 0.33 | 1.61 | 35.2 | 6.82 | 305 |
| 20 | 19×0.190 | 0.96 | 0.33 | 1.62 | 35.2 | 6.82 | 305 |
| 18 | 7×0.390 | 1.19 | 0.33 | 1.85 | 22.2 | 10.81 | 305 |
| 18 | 19×0.235 | 1.18 | 0.33 | 1.84 | 22.2 | 10.81 | 305 |
| 16 | 7×0.500 | 1.53 | 0.33 | 2.19 | 14 | 17.14 | 305 |
| 16 | 19×0.300 | 1.51 | 0.33 | 2.17 | 14 | 17.14 | 305 |
| 14 | 19×0.370 | 1.86 | 0.33 | 2.52 | 8.78 | 27.33 | 200 |
| 12 | 19×0.460 | 2.32 | 0.33 | 2.98 | 5.53 | 43.4 | 200 |
| 10 | 37×0.430 | 3.02 | 0.33 | 3.68 | 3.48 | 68.97 | 100 |
Characteristic
High temperature and low temeprature resistant,anti-acid,anti-oil,antisepsis and moisture,UL758 & UL1581,RoHS compliance,passed VW-1.
Application
Apply to household appliance,illumination & lighting & headlamp,electric machines,temperature sensor,military series,motor cars & ships,electrical installation,etc
FAQ
1. Q: Are you a manufacturer or trading company?
A: We are the leading manufacturer/supplier of heat resistant FEP,PFA,PTFE,ETFE wire and silicone wire in China,meanwhile,we produce halogen free and low smoke XLPE wire,PVC wire,special RG coaxial cable and insulated sleeve/tube.
2. Q: What certifications do you have?
A: We have UL,CUL,VDE,RoHS,REACH and SGS for our wires&cables.
3. Q: How can I get one quotation faster?
A: Pls offer details about your demands as more as possible,such as conductor and insulation material,conductor gauge or cross-sectional area,insulation thickness,over diameter,nominal voltage,working temperature,color,quantity,application,etc.
4. Q: If I can not offer above information,what should I do?
A: Try your best to offer more information,we will help you design suitable wires&cables.
5. Q: What is your company sample policy?
A: As one supplier,we see that sample is necessary for our both sides,our policy is to offer free sample as possible as we can,just one situation is exception,sample is with very complex structure,besides,we have no it in stock.
About sample shippment,you need to pay for the freight,usually freight collect by express.
6. Q: What is the lead time of sample?
A: There are several different situations:
Immediately when you need it if we have it in stock;
1~2days if no stocked sample and the sample structure is not complex;
3~5days if no stocked sample and the sample is with complex structure.
7. Q: Which business term do you prefer?
A: Customer first,you may choose any term,EXW,FOB,CIF,CFR,etc.
8. Q: What is your payment term?
A: We have several payment terms for you,T/T,Western Union,Paypal,L/C,etc.
