plastic film bag 3 color flexo printing machine
Specifications
In feed and Out feed system provided to maintain tension & good registration. Auto Stop for web break. High Printing Quality
Performance and Features
1. Easy operation, flexible starting, accurate color register.
2. The meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.
3. Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
4. The printing ink is spread by the anilox cylinder with even
ink color.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6.360°continuous and adjustable longitudinal register device.
7. The frequency control of motor speed adapts to different
printing speeds.
8. There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the
machine when the plate is installed.
Main Technical Variables:
Model of Machine |
YT-3600 |
YT-3800 |
YT-31000 |
YT-31200 |
Max.Width of Printing Material |
600mm |
800mm |
1000mm |
1200mm |
Max.Printing With |
560mm |
760mm |
960mm |
1160mm |
Length Range of Printed Product |
191-914mm |
191-914mm |
191-914mm |
191-914mm |
Max.Diameter of Roll Material |
φ600mm |
φ600mm |
φ600mm |
φ600mm |
Printing Speed |
70-80m/min |
70-80m/min |
70-80m/min |
70-80m/min |
|
Thickness of plate (Including Two-sides Glue Paper) |
2.38mm |
2.38mm |
2.38mm |
2.38mm |
Total Power |
10.87kw |
12.5kw |
14.37kw |
16.5kw |
Weight of Machine |
3000kg |
3500kg |
4000kg |
4500kg |
Overall Dimensions |
4.2×1.6×2.4mm |
4.2×1.8×2.4mm |
4.2×2×2.4mm |
4.2×2.2×2.4m |
