China Ruian High Speed 4 Colours Film Plastic Bag Roll Printing Machine

Name: China Ruian High Speed 4 Colours Film Plastic Bag Roll Printing Machine
Brand: GUOXIN
SKU: 127453541
Availability: InStock

US$ 25,000 - 40,000 MOQ: 1 Set

Key Specifications

Condition:

New

Plate Type:

Letterpress

Place of Origin:

Zhejiang, China

Wenzhou Qiangtuo Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Plate Type Letterpress

Place of Origin Zhejiang, China

Brand Name GUOXIN

Model Number YT-B

Usage Other, paper printer , label printer , film printer

Automatic Grade Automatic

Voltage 220v/ 380v

Gross Power 20kw

Dimensions(L*W*H) 5300*2400*2400mm

Weight 4500kg

Certification CE,ISO9001

After-sales Service Provided Engineers available to service machinery overseas

plastic bag roll printing machine

CHARACTERISTICS:

1)Ink :Adopt the automatic circle system ,running ink by single small motor ,with the electrical clutch device

2)Timing :Adopt Japanese inverter controlled ,running by small fluctuations

3)Unwinding EPC :adopt the high quality automatic EPC controller device

4)Unwinding and rewinding method : adopt the magnetism Auto tension controller

5)Ink way :our company has special design for the doctor blade device with the ink pump can suck the ink automatically

6)Up and down plate :adopt the hydraulic pressure rising and down the printing plate automatically.

TECHNICAL PARAMETERS:

Pringting width Item	600mm	800mm	1000mm	1200mm	1400mm	1600mm	1800mm	2000mm
Printing color	4 color/colors ( PC : 4+0 , 3+1 , 2+2, 1+4)
Printing material	LDPE : 28 - 100μm LDPE : 30 - 100μm LLDPE : 25 -100μm CPP : 20 -60mic PP : 23 - 65mic NY : 20 - 50mic PETP : 16 ~ 60mic OPP : 18 -70mic BOPP : 17 - 60μm OPA: 20 -60mic Plating film : 30 -80mic Cellophane : 30- 100g /m 2 Paper : 30 -100g /m 2
Printing length	7.5 ″ -40 ″ /7.5 ″ -50 ″ /7.5 ″ -60 ″ /7.5 ″ -70 ″ /7.5 ″ -80 ″
Printing plate lifting system	Pneumatic/Hydraulic press control/Menu
Mechanical speed	90m /min
Printing speed	70m /min
Anilox cylinder	Ceramic :200-500LPI( Japan )
Register precision	Longitude: ± 0.15mm , Transverse: ± 0.15mm
Rewinder/Unwinder DIA	φ 600
Master motor	3.7kw	3.7kw	5.5kw	5.5kw	7.5kw	7.5kw	11kw	11kw
unwinding motor	1.1kw		1.5kw		2.2kw		3.0kw
rewinding motor	1.5kw		2.2kw		3.0kw		3.7kw
Electrical heater	14kw	16kw	20kw	22kw	24kw	26kw	28kw	30kw
Blower of heater	1.5kw x2	1.1kw x3	1.1kw x3	1.1kw x3	1.5kw x3	1.5kw x3	2.2kw x3	2.2kw x3
Blower of nature wind	0.75KW	0.75KW	1.1KW	1.1KW	1.1KW	1.5KW	1.5KW	1.5KW
Inking motor	750w	750w	750w	750w	750w	750w	750w	750w
Bearing	Japan ( NSK)
Unilateral bearing	ASNU( Germany )
NET Weight	4500kg	4750kg	5000kg	5250kg	5500kg	5750kg	6000kg	6300kg
Master Power	25kw	27kw	34kw	37kw	43kw	47kw	55kw	58kw
