Label Printing Machine

Label Printing Machine photo-1
US$ 1 - 2 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Gravure
Place of Origin:
Zhejiang, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Plate Type Gravure
Place of Origin Zhejiang, China
Brand Name Xiaohai
Model Number ZBS-320 label printing machine
Usage Label Printer, Paper Printer, Tube Printer, Other, Label Printer, Paper Printer, Tube Printer, Plastic Film
Automatic Grade Automatic
Voltage 220V~380V
Gross Power 12kw
Dimensions(L*W*H) 2250mX1350m X2800m
Weight 3800kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.adhesive label printing machine to print paper label
2.one machine finish printing,die cutting,sliting in one process

label printing machine





Flexo printing machine is used for printing roll paper,roll coated paper and plastic film etc material.

It is idea equipment for printing the label.

Features:

1, Adopt the ceramic anilox cylinder to transfer the ink.

2, Unwinding and rewinding tension are auto-controlled by tension controller.

3, Each printing unit adopts 3600 plate-adjustment.

4, IR dryer (hot air type) for each printing unit. (UV dryer is for option)

5, This machine has one die-cutting station, and it can make printing and die cutting finished in one process.

6, The ink rollers will be separated from the printing roller, keep running when machine stopped.

7,The machine can finish material-feeding, printing, varnishing, drying, laminating, die-cutting and rewinding in a lump. It is an ideal machine for printing note and top-grade adhesive label.



Main parameters



Printing speed

50m/min

Printing color

5colours

Max. width of paper

320mm

Max .printing width

310mm

Max. unwinding diameter

600mm

Max. rewinding diameter

600mm

Printing length

177.8-355.6mm

Precision of chromatography

±0.1mm

Dimensions

2.25mX1.35m X2.8m (without UV dryer)

Machine weight

About 3800kg

Power supply

380V, 3P, 50/60Hz



label printing machinelabel printing machine
