Specifications
First Person View TX5804 with RC306 32ch AV TX+RX PPM Function 400mw Kit6-28V
TX5804+RC306
Flysight
32ch
First Person View TX5804 with RC306 32ch AV TX+RX PPM Function 400mw Kit
1.Very light and ultra mini size
2. The mini but powerful 5.8G 400mw transmitter would make your fly to 4-5 km away with only the stock antenna, advanced build-in regulator offers this transmitter very wide power input range.
3. Universal Hobbies Radio Control Transmitter With Receiver For The Flying Toys Models is just light, compact and powerful, a very good choice for 5.8G middle range FPV.
This transmitter is compatible with all our 5.8G VRX like RC305, RC805 , AIO goggles and 5.8G DVR DV01.
Specificaitons:
Transmitter(TX5804):
| Transmitter frequency | 5645-5945MHz;8CH |
| Transmitting Power | 400mW/27dBm |
| Transmitting distance | >4000m-5000m(open area) |
| Frequency control | built-in frequency and phase lock loop |
| AV input | analog AV signal input |
| ANT connector | SMA(inside the needle) |
| power supply | 6-16 V |
| Current supply | 280mA |
| Size | 57*27.2*16mm |
| Net weight | 16g(no cable and antenna) |
Remark: The transmitter's power input is ranging from 7-12V,however the voltage outptu from the TX for the camera us 0.5V,lower than the input power.It's suggested to use 3S lipo 11.1V battery.
Note: antennas must be attched before powering on.
Receiver(RC306):
| Receiving frequency | 5665-5945MHz;8CH |
| Receiving sensitivity | -90dBm |
| Frequency control | built-in frequency and phase lock loop |
| Double lines AV output | analog AV signal output |
| Antenna connector | SMA(Inside the needle) |
| Power supply voltage | 6-16V |
| Supply current | 60mA |
| Dimension | 55*40*15mm(aluminium alloy extrusion shell) |
Remark: The receiver's power input is ranging from 8-12V,dual AV output is supported
Note: the av cable uses 3.5mm plug on the receiver RC305
Application reference:
