Specifications
Flysight TX5804+RC306 400mw AV Transmitter+Receiver FPV SetRemote transmitter
TX5804+RC306
Flysight
32ch
Flysight TX5804+RC306 400mw AV Transmitter+Receiver FPV Set
1.Very light and ultra mini size
2. The mini but powerful 5.8G 400mw transmitter would make your fly to 4-5 km away with only the stock antenna, advanced build-in regulator offers this transmitter very wide power input range.
3. Universal Hobbies Radio Control Transmitter With Receiver For The Flying Toys Models is just light, compact and powerful, a very good choice for 5.8G middle range FPV.
This transmitter is compatible with all our 5.8G VRX like RC305, RC805 , AIO goggles and 5.8G DVR DV01.
Specificaitons:
Transmitter(TX5804):
| Transmitter frequency | 5645-5945MHz;8CH |
| Transmitting Power | 400mW/27dBm |
| Transmitting distance | >4000m-5000m(open area) |
| Frequency control | built-in frequency and phase lock loop |
| AV input | analog AV signal input |
| ANT connector | SMA(inside the needle) |
| power supply | 6-16 V |
| Current supply | 280mA |
| Size | 57*27.2*16mm |
| Net weight | 16g(no cable and antenna) |
Remark: The transmitter's power input is ranging from 7-12V,however the voltage outptu from the TX for the camera us 0.5V,lower than the input power.It's suggested to use 3S lipo 11.1V battery.
Note: antennas must be attched before powering on.
Receiver(RC306):
| Receiving frequency | 5665-5945MHz;8CH |
| Receiving sensitivity | -90dBm |
| Frequency control | built-in frequency and phase lock loop |
| Double lines AV output | analog AV signal output |
| Antenna connector | SMA(Inside the needle) |
| Power supply voltage | 6-16V |
| Supply current | 60mA |
| Dimension | 55*40*15mm(aluminium alloy extrusion shell) |
Remark: The receiver's power input is ranging from 8-12V,dual AV output is supported
Note: the av cable uses 3.5mm plug on the receiver RC305
Application reference:
of our company
We are manufacturing and exporting of 5.8Ghz FPV transmitter/receiver, FPV transmitter receiver, monitors/baby monitors , video goggles,mini camera, hd 1080p camera , waterproof sport camera, gopro cable and antenna, and so on for many years with customers from all over the world. our products with high quality and lower price.
- Provide the best service as alibaba Gold Supplier.
- OEM&ODM accepted.
- Top Quality Parts and 1 year Warranties.
- Sufficient Stock and Fast Delivery. And all our product will be strictly tested before delivery
- Price Promise – factory price and the lowest shipping cost.
- The Best Customer Service – 100% of best satisfaction from customers from all over the world.
- Not sold in China to protect the customers' benefits.
- We can shipping all over the world by DHL , TNT ,UPS , FedEx ,By Air and by Sea . The packaging is very safe and strong. If you have any special needs please notify me.
to contact us for more details about Pricing, Packing, Shipping and Discount!
Or If you have any other questions please feel free to contact with me in any time.
