B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 Channels

B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 Channels thumbnail-1
B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 Channels photo-1
US$ 1 - 90 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Flysight
Model Number:
TX5804+RC306 DJI Flame
Use:
Universal, 400mw 5.8ghz Video TX RX 32 channels
Contact Supplier Request Quote Chat Now
Shenzhen Aoweishi Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Flysight
Model Number TX5804+RC306 DJI Flame
Place of Origin Guangdong, China

Specifications

New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channels
5.8ghz
32 channels
Dji flame
TX RX

New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channels



B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channels



B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channels

1.Very light and ultra mini size
2. The mini but powerful 5.8G 400mw transmitter would make your fly to 4-5 km away with only the stock antenna, advanced build-in regulator offers this transmitter very wide power input range.

3. Universal Hobbies Radio Control Transmitter With Receiver For The Flying Toys Models  is just light, compact and powerful, a very good choice for 5.8G middle range FPV.
This transmitter is compatible with all our 5.8G VRX like RC305, RC805 , AIO goggles and 5.8G DVR DV01.



Specificaitons:

Transmitter(TX5804):

Transmitter frequency 5645-5945MHz;8CH
Transmitting Power 400mW/27dBm
Transmitting distance >4000m-5000m(open area)
Frequency control built-in frequency and phase lock loop
AV input analog AV signal input
ANT connector SMA(inside the needle)
power supply  6.5-15 V
Current supply 280mA
Size 57*27.2*16mm
Net weight 16g(no cable and antenna)



Remark:                                       The transmitter's power input is ranging from 7-12V,however the voltage outptu from the TX for the camera us 0.5V,lower than the input power.It's suggested to use 3S lipo 11.1V battery.
Note:                                             antennas must be attched before powering on.



B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channels

  B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channelsB129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channels




Receiver(RC306):

Receiving frequency 5665-5945MHz;8CH
Receiving sensitivity -90dBm
Frequency control built-in frequency and phase lock loop
Double lines AV output analog AV signal output
Antenna connector SMA(Inside the needle)
Power supply voltage 8-12V
Supply current 100mA
Dimension 61*52*13mm  (aluminium alloy extrusion profiles)



Remark:                                    The receiver's power input is ranging from 8-12V,dual AV output is supported
Note:                                          the av cable uses 3.5mm plug on the receiver RC305



Note:antennas must be attched before powering on.


 B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channelsB129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channelsB129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channelsB129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channels



Application reference:



B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channelsB129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channels





B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channelsof our company

We are manufacturing and exporting of  5.8Ghz FPV transmitter/receiver, FPV transmitter receiver, monitors/baby monitors , video goggles,mini camera, hd 1080p camera , waterproof sport camera, gopro cable and antenna, and so on for many years with customers from all over the world. our  products with high quality and lower price.



B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channels

  • Provide the best service as alibaba Gold Supplier.
  • OEM&ODM accepted.
  • Top Quality Parts and 1 year Warranties.
  • Sufficient Stock and Fast Delivery. And all our product will be strictly tested before delivery
  •  Price Promise – factory price and the lowest shipping cost.
  • The Best Customer Service – 100% of best satisfaction from customers from all over the world.



B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channels

  • We can shipping all over the world by DHL , TNT ,UPS , FedEx ,By Air and by Sea . The packaging is very safe and strong. If you have any special needs please notify me.

B129 New Flysight TX5804 400mw 5.8ghz Video TX RX 32 channels to contact us for more details about Pricing, Packing, Shipping and Discount!

Or If you have any other questions please feel free to contact with me in any time.
