Specifications
single axis inclinometer sensor,tilt sensor1.Single axis vlotage-type
2.Long term stability<0.002degrees
3.IP68
4.DC 9-
single axis inclinometer sensor,tilt sensor for Push bench shield machine deviation
Product Description:
HCA510T is a Single-axis inclinometer with voltage output. Its theory is measuring the change of Static acceleration of gravity. It used to compute the dip and pitch degree in respect to the horizontal plane. Product adopts the newest MEMS production technology, so it features high accuracy, small dimension and high anti-EM interference capability as well as under strong shock and impact. At present, it gained the consistent favourable comment of customer in the industry.
Features:
1:Single-axis inclinometer
2:DC 9-36V wide voltage power supply
3:Shockproof is more than 20000g
4:0-5V Output interface
5:Full Metal Jacket,IP68 protection
6:Resolution0.0025°
7:Wide Temperature-40-+100(Degrees Celsius)
8:small size(90*45*29mm)
Applications:
1:Push bench shield machine deviation
2Special vehicles automatic leveling
3:Platform Vehicle,lifter
4:Medical facilities angle control
5:Satellite positioning Search
6:Underground drill posture navigate
