Specifications
LOW-COST INLINOMETER1.Single-axis digital-type
2.Long term stability<0.1degree
3.IP65
4.DC5V power supp(7-36Voptional)
digital output single axis inclinometer with range max +/-90deg
General Description:
LCA316 series is a single-axis inclinometer with low-cost which is researched and produced by China RION company. The maximum measuring range is±90°, This series Output through serial interface RS232 ,RS485 or TTL.
As the built-in newest MEMS production technology, To make this size only: L29mmXW24mm,MEMS technology has very high consistency and stability. It can be widely used in engineering mechanism field.
Features:
1:Single-axis inclinometer
2:Output RS232,RS485,TTL serial interface
3:Measuring range:±1-±90(degrees)
4:Long term stability<0.1(degrees)
5:DC5V power supply(7-36Vcustomizable)
6:Wide Temperature-40~+85(degrees celsius)
7:Shockproof>3500g
8:Resolution0.01(degrees)
9:Full Metal Jacket,IP65 protection
10:small size(40*32*18mm)
Applications:
1:Engineeringmechanical measurement of dip angle
2:Mining mechanism,oil-well drilling equipment
3:Chassis Measurement
4:Electric blind man chair leveling
5:Wheel Alignment
6:Satellite positioningSearch
