Specifications
single axis inclinometer analog current output1.Single-axis current-type
2.Long term stability<0.02degrees
3.IP67
4.DC 9-3
single axis inclinometer analog current output
General Description
SCA118T is a standard industrial output single-axis inclinometer, standard current 4 ~ 20mA output, can be long-distance transmission of up to 2000 meters. The output signal with strong anti-interference, professional be used to work on engineering machinery and equipment in harsh environment. The product uses the latest MEMS sensor production technology for production, made precise compensation and correction to temperature error and nonlinearity error, small measuring range the highest accurate up to 0.03 ° (more precision index, please refer to product Electronic Characteristics), high accuracy , small size, high packaging technology, good capacity to withstand shock and vibration, built-in anti-RF, anti-electromagnetic interference circuit , is particularly suitable for application underground trenchless type of machinery and other harsh industrial environments. In addition to this product is better than the ordinary market product on technical parameters, on the reliability and stability the product is also using the high-end application-level MCU,three-proofing PCB board, imported cable, wide temperature shielded metal enclosure and other measures to improve product industrial level.
Features
*Single-Axis Inclinometer
*Measuring Range :±1~±180° optional
*Accuracy: refer to the technical data
*Wide voltage input: 9~36V
*Output interface : 4-20mA
*Wide temperature working: -40~+85°C
*IP67 protection class
*Highly anti-vibration performance >2000g
*Resolution: 0.0025°
*Small Volume : 90×40×26mm(customized)
Application:
*Engineering vehicles automatic leveling
*Bridge & dam detection
*Aerial platform vehicle,lifter safety & protection
*Medical facilities angle control
*Underground drill posture navigation
*Shield pipe jacking application
*Based on the angle direction measurement
*Geological equipment inclined monitoring
* Equipment level control
*Alignment control , curve control
*Directional satellite communications antenna pitching angle measurement
*Mining machinary, oil-well drilling equipment
Technical Data
Measuring range |
|
±10 |
±30 |
±60 |
±90 |
° |
Measuring axis |
|
X |
X |
X |
X |
|
Zero output |
0° output |
12 |
12 |
12 |
12 |
mA |
Resolution |
|
0.0025 |
0.0025 |
0.0025 |
0.0025 |
° |
Absolute accuracy |
|
0.02 |
0.05 |
0.08 |
0.1 |
° |
|
Long term stability |
|
0.05 |
0.05 |
0.05 |
0.05 |
|
|
Zero temperature coefficient |
-40~85° |
±0.006 |
±0.006 |
±0.006 |
±0.006 |
°/°C |
Sensitivity temperature coefficient |
-40~85° |
≤100 |
≤100 |
≤100 |
≤100 |
ppm/°C |
Power on time |
|
0.5 |
0.5 |
0.5 |
0.5 |
S |
Response time |
|
0.05 |
0.05 |
0.05 |
0.05 |
s |
|
Response frequency response frequence |
|
1~20 |
1~20 |
1~20 |
1~20 |
Hz |
Electromagnetic compatibility |
According to EN61000 and GBT17626 |
|||||
MTBF |
≥50000hours/times |
|||||
Insulation Resistance |
≥100M |
|||||
Shockproof |
100g@11ms,3Times/Axis(half sinusoid)) |
|||||
Anti-vibration |
10grms,10~1000Hz |
|||||
Protection glass |
IP67 |
|||||
Cables |
Standard 1M length,wearproof,grease proofing,wide temperature, Shielded cables4*0.4mm2 |
|||||
Weight |
120g(without cable) |
|||||
* This Technical data only list ± 10 °, ± 30 °, ± 60 °, + 90 ° series for reference, other measuring range please refer to the adjacent parameters
