LCA326T Digital Clinometer, Angle Tilt Sensor ,Belel Box Inclinomete With RS232/RS485/RS422/TTL/CAN/PWM/MOD Optional Interface

Specifications

LCA326T Digital Clinometer , Angle Tilt Sensor , Belel Box Inclinomete With RS232/RS485/RS422/TTL/CAN/PWM/MOD  optional interface

General Description

LCA326Tseries products which launched by RION company is a new generation digital type small size MEMS inclinometer , Built-in two channel gravity tilt unit, by measuring the static gravity acceleration then convert into the inclination change. Thus can measure the inclinometer output relative to the horizontal tilt and pitch tilt. Output RS232, RS485 or TTL level interface standard optional. Because of built-in MCU control system, that make the sensor output linearity get two amendments, made up the analog type precision drop because of insufficient correction led to .

This product adopts the non-contact measuring principle, can real-time output the current attitude angle, simple to use, no need to find the relative variation of the two surface for mounting. It is a ideal choice for Industrial automation control and platform measuring attitude,strong ability of resisting external electromagnet interference, can be adapted to long-term working in the industry harsh environment. This product is suitable for the static and slow changes dynamic measurement, not suitable for rapid changes dynamic measuring.

Features

• Dual-Axis Inclinometer
• Measuring Range :±10~±90° optional
• Long-term stability 0.2°
• DC+5V input
• Output mode RS232/RS485/TTL (optional)
• Wide temperature working: -40~+85°C
• IP67 protection class
• Highly anti-vibration performance >3500g
• Resolution: 0.05°
• Small size : 55×37×24mm(customized)

Application

• Electric blind man chair leveling
• Cloud deck operating monitor
• Satellite antenna positioning
• Medical equipment leveling
• Car Chassis Measurement
• Four - wheeled positioning system
• engineering mechanical measurement of dip angle
