Right Angle Solder Sma Military Connector
- shanghai
- T/T D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | db | |
| Model Number | OPT-SMA- | Type | SMA | |
| Application | RF | Gender | Female |
Product Description
Specifications
SMA military connectorbrass Plating: gold
type:SMA connector
apllication:microwave and rf
military connector ISO9001
right angle solder sma military connector
SMA military connector:
SMA connectors has many advantages, such as small size, wide frequency range, excellent signal properties and high reliability. SMA connectors are mostly used in RF and Microwave Industries .
| Material |
| Center contacts |
Technical Specification of sma connector
Temperature Range | -65 to +155 Deg.C |
Impendance | 50 Ω , |
Frequency Range | DC to 4 GHz Max(50 Ω); DC to 2 GHz Max(75 Ω) |
Insertion Loss | 0.1 dB Max @ 1 GHz |
VSWR Straight | ≤1.25 |
VSWR Right angle | ≤1.45 |
Working Voltage | 335 V @ SEA LEVEL |
Withstand Voltage | 1000 V @ SEA LEVEL |
Contact resistance | Center Contact ≤6 mΩ |
Contact resistance | Outer Contact ≤1 mΩ |
Insulation Resistance | ≥1000 MΩ |
Durability(mating) | ≥500 cycles |
