RF Lmr 240 Coaxial Cable 50 Ohm N Connector SMA RF Connector

Name: RF Lmr 240 Coaxial Cable 50 Ohm N Connector SMA RF Connector
Brand: RF connector
SKU: 124548969
Availability: InStock

US$ 0.2 - 2 MOQ: 1000 Pieces

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

RF connector

Model Number:

RF CONNECTOR

Yangzhou Dongbei Electronic Equipment Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name RF connector

Model Number RF CONNECTOR

Type SMA

Application RF

Gender Male

Product Description

RF coaxial cable 50 ohm coaxial SMA RF Connector

Type SMA is one kind of RF coaxial connectors that is widely applied, with small-sized thread coupling
The characteristic of connectors is in wide frequency range, excellent performance, high reliability.
They are used in connection with RF cable or micro-strip line in RF circuit of the WLAN system, controlled program, microwave equipment and digital communication system.
The frequency can be up to 18GHz by using semi-rigid or semi-flex cable.

Radio Frequency (RF) connectors:

*//* MMCX, MCX, SMA, SSMB, SMB, BNC, TNC, N,.F CONNECTOR

*//*RF Connectors division of RF Industries designs and manufactures an extensive line of radio frequency

*//*(RF) coaxial connectors used in wireless telecommunications applications,

*//*including WiFi, PCS, radio,computer networks, test instruments and antenna devices.

High quality SMA male connector for use with TriLan 240 .

The connector can be used up to 6 GHz.

It features low insertion loss and high return loss.

5-6 GHz systems require specially designed quality connectors

that ensure optimal parameters.

Connector type	SMA connector	Insertion Loss	dB maximum = .03√[f(GHz)]
Frequency Range	.141" & .085" semi-rigid cable: 0-18 GHz Flexible cables: 0-12.44GHz	RF Leakage	-60 dB minimum
Impedance	50 Ω	Connector Affixment to Cable	Crimp and solder types
Contact Resistance	Inner contact: max 6 mΩ	Material	Shell: Brass
	Inner contact: max 6 mΩ		Shell: Brass
	Outer contact: max 2 mΩ		Contacts:Beryllium copper
Insulating resistance	5,000 MΩ minimum		Gaskets: Silicone rubber
Withstanding voltage	.141" & RG-58 Cables: 1,000 VRMS .085" & RG-316 Cables: 750 VRMS	Temperature Range	- 65°C to +165°C
Withstanding voltage		Temperature Range	- 65°C to +165°C
