Specifications
sma male connector1.High quality
2.Best service
3.Factory prices
4.OEM accepted
rg174 rg316 rg58 coaxial cable crimp sma connector right angle sma male connector
| Key Performance | ||||||
| Temperature range | -65~+165 | Insulation resistance | ≥5000MΩ | |||
| Characteristic impedance | 50Ω | Dielectric Withstanding voltage | 1000V(r ms) | |||
| Frequency range | With flexible cable | 0~12.4GHz | Contact resistance | Center conductor | ≤3mΩ | |
| With semi-rigid/flexible cable | 0~18GHz | Outer conductor | ≤2mΩ | |||
| VSWR | With flexible cable | ≤1.15+0.02F | Durability | 500 Cycles | ||
| With semi-rigid/flexible cable | ≤1.05+0.02F | |||||
| Material And Plating | ||||||
| Body | Brass , gold plated or stainless steel passivated | |||||
| Male center contacts | Brass , gold plated | |||||
| Female center contacts | Beryllium copper , gold plated | |||||
| Insulators | PTFE | |||||
| Gaskets | Silicon rubber | |||||
| Crimp ferrules | Copper alloy , gold or nickel plated | |||||
| Applications | Base stations, cable assemblies, components, instrumentation, Mil/Aero, PC/LAN, process controls and telecom |
| Applicable Standard | MIL-C-39012, CECC 22110, IEC 60169-15 |
*-----SMA connectors are semi-precision, subminiature units that provide excellent electrical performance from DC to 18 GHz
*-----SMA connectors for semi-rigid coaxial cables and the SMA Plug-to-Jack adapter offer a precise and simple means of phase adjustment for microwave devices
*-----SMA is available both in Standard and Reverse Polarity. Reverse polarity is a keying system accomplished with a reverse interface, and ensures that reverse polarity interface connectors do not mate with standard interface connectors
SMA male connector Plating Dold Show
SMA male connector Plating Nickel Show
