Female Straight Pcb Mount Connector SMA
Negotiable
MOQ: 500 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Dongbei
Model Number:
db-010
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Gold Plated Smb Female rf Adapter Connector From Dongbei FactoryUS$ 0.1 - 1.5MOQ: 1000 Pieces -
2013 High Quality Right Angle Sma rf Male ConnectorUS$ 0.1 - 1.5MOQ: 5000 Pieces
-
2013 Dongbei Smb Direct Insertion Female rf Coaxial Cable ConnectorUS$ 0.1 - 0.65MOQ: 2000 Pieces
-
50ohm SMA Female Right Angle Connector for PCB MountingUS$ 0.1 - 0.9MOQ: 2000 Pieces
-
Rg174 Rg316 Rg58 Coaxial Cable Crimp Sma Connector Right Angle Sma Male ConnectorUS$ 0.1 - 0.9MOQ: 3000 Pieces
Place of Origin
Jiangsu, China
Brand Name
Dongbei
Model Number
db-010
Type
Other, SMA, SMA-KE-P
Application
RF
Gender
Female
Specifications
sma pcb mount connector1) wide frequency range
2) popular design
3) excellent electrical performances
4) CE certificater
sma female straight pcb mount connector
| Connector type | sma pc mount connector | Working Voltage | 335V max |
| Frequency Range | DC-12GHz |
vswr | max 1.3 |
| Impedance | 50Ω | Temp.range | -25~+60°C |
| Conductor resistance | Internal ≤ 6mΩ | Material | Shell:brass, gold plated |
| External ≤ 2mΩ | Nut:brass, gold plated | ||
| Insulating resistance | ≥ 5000 MΩ | pin:brass,gold plating | |
| Withstanding voltage | 400V rms | Applicable standard | IEC 60169-24 |
| Parts Name | Material | Finish | |
| Center Contact | Male | Brass | 3u" Gold |
| Female | brass | 3u" Gold | |
| Body, Metal Parts | Brass | Nickel or Gold per requirement | |
| Insulators | PTFE | None | |
| Gasket | Silicone Rubber | None | |
| Crimp Ferrule | Annealed Copper | Nickel or Gold per requirement | |
- Manfactured of high quality brass with nickel plating of superior protection against v-corrosion
- Offer excellent RFI shielding properties
