HG273 Steel Tube Mill

Name: HG273 Steel Tube Mill
Brand: ztzg
Availability: InStock

FOB Price

US$ 400,000 - 700,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hebei, China		Brand Name	ztzg
Model Number	HG273

Commodity:steel tube mill
1,Pipe OD:114-273mm
2,Thickness:3-10mmmm
3,Length:6-12m
4,Material: low carbon or alloy steel

Commodity	steel tube mill
Round Pipe Size(mm)	114mm - 273mm
Pipe Thickness (mm)	3mm-10 mm
Square Pipe Size(mm)	90mm90mm-210mm210mm
Pipe Thickness (mm)	3mm-9 mm
Material	Carbon steel coil(GB Q195-Q345); Alloy steel coil; API 5L X42-X80
Pipe Length(m)	6 -12m
Length Tolerance(mm)	±3mm
Line Direction	right or left(from operator's side)
Production Speed(m/min)	0-45m/min
Low Carbon Steel And Low Alloy Steel:	δb≤550Mpa ,δs≤235Mpa
Technical Flow	Scroll up→ Uncoil→ Flattening→ Cutting head, tail→ Strip Steel head-tail butt welding→ Looping storage→ Forming→ High-frequency induction welding→ Removing external burr→ Cooling→ Cutting→ Checking & Collecting→ Binding→ Accessing Warehouse.
Tube Bottom Pass line/ Line Power/ Electricity Input Power etc.	Belong to confidential information and detail parameters will be known in the quotation list.
