Good quality Filter press wastewater treatment Higt efficiency
- 1000 Set / Sets per Month
- Qingdao Shanghai Ningbo
- T/T
- Small Efficient vertical automatic laboratory belt filter press with advanced design
- China professional manufacturer fruit belt press filter
- belt extractor for press juice from fruit and vegetables
- Automatic fruit press belt equipment apple juicer machine
- Ion Exchange Nozzles for Intermediate Plate
- CHAMBER FILTER PRESS
Product Details
Condition: | New | Automatic Grade: | Automatic | Production Capacity: | More |
Place of Origin: | Henan, China | Brand Name: | GT | Model Number: | GT-FS |
Voltage: | 220V-480V | Power(W): | 2.2kw | Weight: | 2500kg |
Dimension(L*W*H): | 4380*1490*1365 | Certification: | CE/ISO | Warranty: | One year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Advantages:
1. Wally controlled by PLC and reserves DCS remote interface.
2. Filter press wastewater treatment with automatic Hydraulic maintaining pressure.
3. Hydraulic pistons are made by steel 45 after surface processing with feature of high hardness, anti-wearing, long life-span.
4. Main beam is made of high quality carbon steel with sand blasting processing and it is of high intensity and corrosion resisting Filter press wastewater treatment
5. Pure reinforced PP filter plate resists to stronger corrosion and endure high pressure and service longer.
6. Every plate is tested under high closing pressure 27 Mpa.
7. The flatness of the filter plate is lower than 25μm.
8. Our plate shifting system features easy operation, low noise and simple maintenance.
9. Automatically discharging to perform the best efficiency.
Features
1.Tot-level automation, energy-saving
2.High efficiency, easy to use and maintain Stainless steel hydraulic filtering press machine
3.Separation effect is good, wide application Stainless steel hydraulic filtering press machine
Application:filtering press machine widely used in coal washing, inorganic chemicals, mining, alcohol, petroleum, metallurgy, chemicals, fuel, medicine, food, textile, printing and dyeing, paper making and sewage treatment and other fields.
Technology parameters
Form | filter press model | filter area(m2) | size (mm) | cake thickness (mm) | qty of plate | chamber volume(L) | filter pressure(Mpa) | size | ||
length (mm) | width (mm) | height (mm) | ||||||||
320 | XS1/320-30U | 1 | 320*320 | 30 | 4 | 15 | 1 | 1200 | 660 | 650 |
XS2/320-30U | 2 | 9 | 31 | 1515 | ||||||
XS3/320-30U | 3 | 14 | 46 | 1755 | ||||||
450 | XS4/450-30U | 1 | 450*450 | 30 | 9 | 61 | 0.6 | 1860 | 870 | 870 |
XS6/450-30U | 6 | 14 | 91 | 2120 | ||||||
XS8/450-30U | 8 | 19 | 122 | 2380 | ||||||
XS12/450-30U | 12 | 29 | 182 | 2880 | ||||||
XS16/450-30U | 16 | 39 | 243 | 3380 | ||||||
630 | X20/630-30U | 20 | 630*630 | 30 | 24 | 298 | 0.6 | 3350 | 1150 | 1150 |
X30/630-30U | 30 | 37 | 453 | 4000 | ||||||
X40/630-30U | 40 | 47 | 595 | 4600 | ||||||
800 | X50/800-30U | 50 | 800*800 | 30 | 38 | 749 | 0.6 | 4205 | 1400 | 1300 |
X60/800-30U | 60 | 46 | 902 | 4670 | ||||||
X70/800-30U | 70 | 54 | 1056 | 5115 | ||||||
X80/800-30U | 80 | 62 | 1210 | 5560 | ||||||
1000 | X50/1000-30U | 50 | 1000*1000 | 30 | 28 | 752 | 0.5 | 3800 | 1450 | 1350 |
X60/1000-30U | 60 | 34 | 908 | 4260 | ||||||
X70/1000-30U | 70 | 40 | 1064 | 4520 | ||||||
X80/1000-30U | 80 | 45 | 1194 | 4820 | ||||||
X90/1000-30U | 90 | 51 | 1349 | 5170 | ||||||
X100/1000-30U | 100 | 57 | 1505 | 5530 | ||||||
X120/1000-30U | 120 | 68 | 1790 | 6200 | ||||||
1250 | X100/1250-30U | 100 | 1250*1250 | 30 | 36 | 1519 | 0.5 | 4500 | 1750 | 1550 |
X120/1250-30U | 120 | 43 | 1807 | 4910 | ||||||
X140/1250-30U | 140 | 50 | 2094 | 5320 | ||||||
X160/1250-30U | 160 | 58 | 2423 | 5800 | ||||||
X180/1250-30U | 180 | 65 | 2710 | 6210 | ||||||
X200/1250-30U | 200 | 72 | 2998 | 6720 | ||||||
X250/1250-30U | 250 | 90 | 3737 | 7750 | ||||||
1500 | X200/1500-30U | 200 | 1500*1500 | 30 | 50 | 2999 | 0.5 | 6150 | 2130 | 1900 |
X250/1500-30U | 250 | 63 | 3764 | 7060 | ||||||
X300/1500-30U | 300 | 76 | 4528 | 7940 | ||||||
X350/1500-30U | 350 | 89 | 5292 | 8850 | ||||||
X400/1500-30U | 400 | 101 | 5998 | 9740 | ||||||
X450/1500-30U | 450 | 114 | 6762 | 10650 | ||||||
X500/1500-30U | 500 | 127 | 7527 | 11570 |
Filter press types
Jack pressed filter press, Manual pressed filter press, Program-controlled automatic filter press, Chamber filter press, Plate-frame filter press, Mechanical filter press, Hydraulic filter press, Membrane filter press, Full-automatic filter press, DU rubber belt vacuum filter, Belt filter press and filter press spare parts.
Shipment
Please contact with Ms. Echo
