Specifications
AXWYT-1200 simple type Non-woven fabric Flexographic Printing Machine1) Easy operation
2) Flexible starting
3) simple type
AXWYT-1200 simple type Non-woven fabric Flexographic Printing Machine
Characteristics:
1. Easy operation,flexible starting, accurate colour register.
2. The printing ink spread by the knurled with even ink colour.
3. Reliable drying syetem coordinated with high-speed rotation ,it will automatically
breakcircuit when the machine stops.
4. 360°continuous and adjustable longitudinal register device
5.Frequency control of motor speed adapts to differents printing speeds
6. Main motor frequency control
7. Main motor power is 4kw
8. Rewinding adopts magnetic powder clutch is 5kg, unwinding adopts friction plate
9. Main printing roller adopts special steel, the thickness of electroplating which protective layer of hard chromium is 10 Ounce
10. Rubber roller &110mm hardness is 65-70,characteristics:soft and hard steel combinate . tension to ensure that there is divided into sections; steel roll is power roll, using the same motor through a gear drive, driving accuracy has safeguards; the overall design of wall panels to work closely to ensure the accuracy of the final installation
11. Main Printing roller gears is M2
12. Electric adopts Chinese Zhengtai,main motor transducer adopts Shanghai Nengshi
Main Technical Variables:
Model Machine |
WYT3-1200 | WYT3-1400 | WYT3-1600 |
| Max width of Printing Material | 1200mm | 1400mm | 1600mm |
| Max Printing width | 1160m | 1360m | 1560m |
| Max Length Range of Printed product(mm) | 191-800 | 191-880 | 191-880 |
| Max Diameter of Roll Material | &1000mm | &1000mm | &1000mm |
| Printing speed | 5-50min | 5-50min | 5-50min |
| Thickness of Plate(including two-sided Glue Paper) | 4.00mm | 4.00mm | 4.00mm |
| Total power | 19kw | 21kw | 23kw |
| Weight of machine | 3100kg | 3300kg | 3500kg |
| Overall Dimensions mm | 3580x2200x2500 | 3580x2400x2500 | 3580x2600x2500 |
