Dahua horizontal rotary axis automatic dispensing robot
Introduction:
Dahua’s robot is designed for dispensing on side elevation of different products,it’s new design product in this dispensing glue industry already.
1.Equipped with the rotating way of three-axis association which solve the problem of dispensing glue on side elevation.
2.It can dispense glue with dots,strips,arcs and patterns on different planes or curved surface.
3.Different glue control systems can be chosen according to different glues,the speed can be adjusted.
4.as the center of products, to design jig for good concentricity, convenient is expected to take up and down.
Application
Generally suitable for dispensing glue on thread,side elevation of cylinder and oval.
specification:
X/Y/Z working range: 300 x 300 x 100mm
Standard : the factory standard
XY/Z Maximum Load : 8 kg / 2 kg
XY/Z Speed: 0.1-800/350mm/Axis
Repeatability: ±0.02mm/Axis
Data memory capacity : it can store 10000 profiles,8000 traces in each profile.
Display way :LCD display
Safety protection:photoelectric sensor
Edit Programming :hand-held programmer
I/O Signals: 4 Inputs / 4 Outputs
Patterns : dots/strips/arcs/3D track
Power Supply: AC220V/350W
Working Temperature: 0 ~40℃
Relative Humidity: 20~90% (no condensation)
Complete accessories dispensing kit other relation product
NO |
Name |
QTY |
ITEM |
1 |
TH-2004D1 Robotic |
1pcs |
TH-2004D1 |
2 |
Teach pendant/ fix frame |
1pcs |
TH-DT001 |
3 |
Teach pendant Cable line |
1pcs |
TH-DTC01 |
4 |
Dispenser |
1pcs |
customs |
5 |
Dispenser fix frame |
1set |
TH-DXF03 |
6 |
valve |
1set |
|
7 |
Dispensing tip |
10pcs |
|
8 |
POWER cord 220V |
1pcs |
TH-DP06 |
9 |
Manual operation |
1pcs |
|
10 |
Ex-work Report |
1pcs |
|
11 |
Machinery certificate |
1pcs |
|
12 |
Warranty card |
1pcs |
|
13 |
CE certificate |
1pcs |
|
14 |
catalogue |
1pcs |
|
Drawing:
Our factory
Warehouse
