Help CenterBest Supplier 2 Color Nonwoven Flexographic Printing Machine
Related Products
-
6 Color Printing Machine and Multi PrinterUS$ 8,000 - 36,000MOQ: 1 Set -
Paper or Plastic Film Flexo Printing Machines 8colors Color Multifunction Flexo Printing MachineUS$ 6,000 - 45,000MOQ: 1 Set
-
Bag Printing Machine Milk Bag Film Printing MachineUS$ 6,500 - 20,000MOQ: 1 Set
-
High Speed Roller Bag Flexo Printing MachineUS$ 6,500 - 45,000MOQ: 1 Set
-
Letterpress Plate Type Multicolor Color Four Colours High Speed Flexo PrinterUS$ 9,000 - 50,000MOQ: 1 Set
nonwoven flexographic printing machine use for plastic film and paper cup or bags
PRODUCTS WORKSHOP
1. Safety first, quality first .
2. Strict and advanced workshop management system .
3. The human production, people-oriented .
4. High quality products to provide high quality environment
2 colour flexo printing machine ◊The main features:
1. Take it easy, accurate color, long life.
2. Use motors, variable frequency speed control, saving electricity, small running fluctuations.
3. Off printing roll automatic stop the ink-running motor, and up-printing roll automatic start running the ink.
4. Use special synchronous belt drive, accurate printing size.
5. Two sets of heating devices, including central heating and constant temperature control system for group control.
6. Lowroller special steel processing, and special process, and plating thickness of 0.1mm protective layer of hard chromium.
7 Alloy roll with hard oxidation, treating by dynamic balance, static balanced.
8 With cold wind bellows, and can effectively prevent produce with ink adhesion after printing
9. Print produce are clear and good arrangement quality.
10. Bearing: NSK, Japan Brand, Germany ASNU aluminum alloy roll
◊Main Technical Variables
Type |
YT-2600 |
YT-2800 |
YT-21000 |
YT-21200 |
Max. Effective Printing Width |
560mm |
760mm |
960mm |
1160mm |
Max. Web Width |
600mm |
800mm |
1000mm |
1200mm |
Max. Printing Speed |
50m/min |
50m/min |
50m/min |
50m/min |
Max. Mechanical Speed |
60 m/min |
60 m/min |
60 m/min |
60 m/min |
Max. Diameter of Roll Material |
450mm |
450mm |
450mm |
450mm |
Internal Diameter of Roll Core |
76mm |
76mm |
76mm |
76mm |
Rang of Repeat Printing Length |
191-914mm |
191-914mm |
191-914mm |
191-914mm |
Accuracy of Registration |
±0.5mm |
±0.5mm |
±0.5mm |
±0.5mm |
Plate Thickness(Both side adhesive included) |
2.38mm |
2.38mm |
2.38mm |
2.38mm |
Heating Power |
4Kw |
6Kw |
8Kw |
10Kw |
Total Power |
8Kw |
10Kw |
12Kw |
14Kw |
Weight of Machine |
1800kg |
2000kg |
2200kg |
2600kg |
Overall Dimension(L*W*H) mm |
2500×1700×2200 |
2500×1900×2200 |
2500×2100×2200 |
2500×2300×2200 |
2 colour flexo printing machine Photo
- Understand your needs
- Individual machine is designed upon user’s need
- In-time service
- On-line / overseas technical support
- Fast delivery
- Always here for your service
