multi-color flexo printing machinery
Main Technical Parameter | |
Max. Roll Width |
1000mm |
Max. Printing Width |
960mm |
Printing Length |
191-1000mm |
Printing Colors |
8+0, 7+1, 6+2 and 4+4 |
Printing Plate Lifting System |
Hydraulic press control |
Max. Mechanical Speed |
80m/min |
Max. Printing Speed |
70m/min |
Anilox Roller |
Ceramic Roller |
Dimension |
4800m×2250×3200mm |
Specifications |
High Speed Precision Roll Flexographic/Flexografic Printing Machine 10 Colors is suitable for various materials roll to roll printing, like various paper, film(BOPP,PET,PE,OPP), Non woven fabric, woven bags, labels, cloths, etc. |
Main |
1. Flexographic Printing Machine 10 Colors is with PLC control and HMI, all working parameters can be preset and displayed on the control panel. |
2. This roll to roll printing machine is with automatic hydraulic lift up loading system for heavy material roll loading. |
3. Flexographic Printing Machine 10 Colors is with 2 sets automatic tension controller to provide constant tension control. |
4. Roll to Roll Flexo Printing Machine is with 1 set 10kg/2 magnetic brake to help tension control in unwinding part. |
5. Flexographic Printing Machine 10 Colors is with photocell tracking system to keep accurate roll edge. |
6. Flexographic Printing Machine 10 Colors is with 3’’ air expanding shaft for roll material loading |
7. Flexographic Printing Machine 10 Colors is with automatic meter counter, which can count the working length. When reached the preset length, machine can stop automatically. |
8. Low speed and full load startup; stable running by tension control when speed up or down, low noise. |
