Flexographic Ceramic Roller Printing Machine High Speed 8 Color Flexographic Printing Machine Quality Choice

Main Technical Parameter

Max. Roll Width

800mm

Max. Printing Width

760mm

Printing Length

191-1000mm

Printing Colors

4+4,3+5, 1+7,2+6,8+0

Printing Plate Lifting System

Hydraulic press control

Max. Mechanical Speed

80m/min

Max. Printing Speed

70m/min

Anilox Roller

Ceramic Roller

Dimension

6800m×2300×2600mm

Specifications

      Flexographic Ceramic Roller Thermal Paper Till Roll Printing Machine is suitable for various materials roll to roll printing, like various paper materials, film(BOPP,PET,PE,OPP), Non woven fabric, woven bags, pp sacks, cloths, labels, foils, etc.

Main

1. Flexographic Ceramic Roller Thermal Paper Till Roll Printing Machine is with PLC control and HMI, all working parameters can be preset and displayed on the control panel.

2. Machine is with automatic hydraulic lift up loading system for heavy material roll loading.

3. Machine is with 2 sets automatic tension controller to provide constant tension control.

4. Machine is with 1 set 10kg/2 magnetic brake to help tension control in unwinding part.

5. Machine is with photocell tracking system to keep accurate roll edge.

6. Thermal Paper Roll Printing Machine is with 3’’ air expanding shaft for roll material loading.

7. Thermal Paper Roll Printing Machine is with automatic meter counter

8. Low speed and full load startup; stable running by tension control when speed up or down, low noise.

1. Customize is available

2. 24 hours online service

3. After sales service: engineers are available to service overseas

4. In the warranty time, we will provide free parts replacements and maintenance service.

5. Our machine is with whole life technical support.

Q: Are you a factory or trading company?

A: We are manufacturer, have our own factory. We not only sell machines, but also provide business solutions for you.

Q: What kind of quality certificate do you have?

A: We have CE certificate, SGS, ISO, etc.

Q: How about the delivery time of machines?

A: Usually, our machines can be delivered within 30 working days.

Q: What’s the payment terms?

A: Usually, we do T/T with 30% deposit, and 70% balance paid before machine delivery. And L/C, western union, etc are also acceptable. Payment terms can be discussed with us.

Q: If come to visit, how can I go to your factory?

A: Welcome your visiting. We are in Ruian, Zhejiang Province, the transportation is convenient. It is about 30-40 min from airport to our factory, and 20min from the train station.
