Fully Automatic PP Woven Bag 4-Colour Flexo Printing Machine,High Effect Stable Plastic Bag Printing Machine

Main Technical Parameter

Max. Roll Width

800mm

Max. Printing Width

760mm

Printing Length

191-1000mm

Printing Colors

4+0,3+1 and 2+2

Printing Plate Lifting System

Hydraulic press control

Max. Mechanical Speed

80m/min

Max. Printing Speed

70m/min

Anilox Roller

Ceramic Roller

Dimension

4800m×1800×2600mm

Specifications

   plastic bag printing machine  is suitable for various materials roll to roll printing, like paper, film(BOPP,PET,PE,OPP), non woven fabric, woven bags, pp woven sacks, labels, foils, etc.

Main

1.  plastic bag printing machine is with PLC control and HMI, all working parameters can be preset and displayed on the control panel.

2.  plastic bag printing machine is with automatic hydraulic lift up loading system for heavy material roll loading.

3.  plastic bag printing machine is with 2 sets automatic tension controller to provide constant tension control. One for  for unwinding and one for rewinding part.

4.  plastic bag printing machine  is with 1 set 10kg/2 magnetic brake to help tension control in unwinding part.

5.  plastic bag printing machine  is with photocell tracking system to keep accurate roll edge.

6. It is with 3’’ air expanding shaft for roll material loading. Also can provide as your request.

7.  plastic bag printing machine  is with automatic meter counter, which can count the working length. When reached the preset length, machine can stop automatically.

8. Low speed and full load startup; stable running by tension control when speed up or down, low noise.
