Home > Products > Printing Machine > Printing Machine Spare Part
Printing Machine Spare Part
- Ningbo / Shanghai
- T/T Money Gram Credit Card
You May Like
Product Details
| Condition | New | Plate Type | Letterpress | |
| Place of Origin | Zhejiang, China | Brand Name | JINGDIANRUIHUA | |
| Model Number | GAYT-6600/6800/62000 | Usage | Paper Printer, Other, Paper Printer, paper pe film pp film printing machine | |
| Automatic Grade | Automatic | Voltage | 380V/220V440 | |
| Gross Power | 58kw | Dimensions(L*W*H) | 4.8m*3.2m*2.8m | |
| Weight | 6300kg | Certification | CE/SGS | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
NAME: flexographic Print machine
USE:BOPP Computer control GAYT 6 colors flexo printing machinery suitable for plastic material,paper,pp woven,foil etc.
Detailed Product Description
-Main Technical Parameter:
1. Low speed and full load startup; stable running by tension control when increasing and decreasing speed, noise is decreased
2. High dots presentation rate under high speed; clear and vivid stratification of screen printing; strong stereo effect and accurate registering
3. Aluminum roller adopts the Japan semi-sealing small bearing; flinty oxidation, static and dynamic balancing treatments are conducted; low resistance and small flop.
4. The special made modulus angular gears adopted printing size and full printing specifications (5mm is spec)
5. With the air exhaust, blowing and heating settings; the heating system adopts the central thermostatic control system and group management, also with the cold air forming devices
6. Printing rolls should keep moving while machine halted
7. Material holder use air shaft
8. Auto tension control
9. Unwind with auto deviation correction system (EPC)
10. EDGE position control
11. Reversible printing 6 color press for 6+0,1+5,2+4,3+3
12.1 set of printing cylinder, size 15 inches
printing width Item | 600mm | 800mm | 1000mm | 1200mm | 1400mm | 1600mm | 1800mm | 2000mm |
Printing color | 6(PC:6+0,4+2,5+1,3+3) | |||||||
Printing length | 7.5”-40”/7.5”-50 | |||||||
Printing plate lifting system | Hydraulic press control | |||||||
Menchanical speed | 140m/min | |||||||
Printing speed | 80m-120/min | |||||||
Anilox cylinder | Ceramic anilox roller | |||||||
Register precision | Longitude:±0.20mm,Transverse±0.20mm | |||||||
Rewinder/UnwinderDIA | φ600mm | |||||||
Master motor | 3.7kw | 3.7kw | 5.5kw | 5.5kw | 7.5kw | 7.5kw | 11kw | 11kw |
Unwinder motor | 1.1kw | 1.5kw | 2.2kw | 3.0kw | ||||
Rewinder motor | 1.5kw | 2.2kw | 3.0kw | 3.7kw | ||||
Electrical heater | 14kw | 16kw | 20kw | 22kw | 24kw | 26kw | 28kw | 30kkw |
Blower of heater | 1.5kw*2 | 1.1kw*3 | 1.1kw*3 | 1.1kw*3 | 1.5kw*3 | 1.5kw*3 | 2.2kw*3 | 2.2kw*3 |
Blower of nature wind | 0.75kw | 0.75kw | 1.1kw | 1.1kw | 1.1kw | 1.5kw | 1.5kw | 1.5kw |
Inking motor | 370w | 750w | 750w | 750w | 750w | 750w | 750w | 750w |
Master frequency converter | (Panasonic)/ (Toshiba)transducer Japan | |||||||
Bearing | Japan(NSK) | |||||||
Unilateral bearing | ASNU(Germany) | |||||||
Weight | 4500kg | 4750kg | 5000kg | 5250kg | 5500kg | 5750kg | 6000kg | 6300kg |
Master Power | 25k | 27kw | 34kw | 37kw | 43kw | 47kw | 55kw | 58kw |
Dimension(L*W*H) | 4.8m* 1.8m* 2.8m | 4.8m* 2.0m* 2.8m | 4.8m* 2.2m* 2.8m | 4.8m* 2.4m* 2.8m | 4.8m* 2.6m* 2.8m | 4.8m* 2.8m* 2.8m | 4.8m* 3.0m* 2.8m | 4.8m* 3.2m* 2.8m |
COMPUTER CONTROL COLOR REGISTRATION SYSTEM:
HYDRAULIC PRESSURE SYSTEM FOR JUMBO MATERIAL:
Our Capacity:
1)Sales Market:Domestic and Overseas markets
2)About QC: Excellence, quality first is our philosophy
3)Main Products:Plastic machinery specially in blown film machines
Our Service:
1.Installation Services
Installation Services are available with all new machine purchases. We will provide the technical know-how for your operation smooth transition and support for installing, debugging, operation of the machine, it will indicate you how to use this machine well.
2.Clients Traning Services:
We can train your staff to use your equipment systems properly.It means that we offer Customers Training, teaching how to use the systems most efficiently and safely as well as how to maintain optimal operational productivity.
3.After Sales Service:
We offer the Preventative Maintenance and After Sales Service. For we strongly feels about the importance of supporting our customers and the product solutions we provide.Consequently we offer comprehensive maintenance options to prevent equipment issues before they become problems. Also we offer one year guarantee period.
In one words,your satisfication is our persuit forever!
