Non Woven Bag Printing One Color Machine Good Price

Main Technical Parameter

Max. Roll Width

1000mm

Max. Printing Width

960mm

Printing Length

191-1000mm

Printing Colors

2 colors

Printing Plate Lifting System

Hydraulic press control

Max. Mechanical Speed

80m/min

Max. Printing Speed

70m/min

Anilox Roller

Ceramic Roller

Specifications

      Non Woven Bag Printing One Color Machine Good Price is suitable for various materials roll to roll printing, like paper, film(BOPP,PET,PE,OPP), Non woven fabric, woven bags, PP woven sack, label, etc.

Main

1. Non Woven Bag Printing One Color Machine Good Price is with PLC control and HMI, all working parameters can be preset and displayed on the control panel.

2. Machine is with automatic hydraulic lift up loading system for heavy material roll loading.

3. It is with 2 sets automatic tension controller to provide constant tension control.

4. Machine is with 1 set 10kg/2 magnetic brake to help tension control in unwinding part.

5. Machine is with photocell tracking system to keep accurate roll edge.

6. Non Woven Bag Printing One Color Machine Good Price is with 3’’ air expanding shaft for roll material loading. Also can provide as your request.

7. Machine is with automatic meter counter, which can count the working length. When reached the preset length, machine can stop automatically.

8. Low speed and full load startup; stable running by tension control when speed up or down, low noise.
