GIGA LX Flexo Carton Box Cutting Machine
US$ 180,000 - 400,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Letterpress
Place of Origin:
Shanghai, China
Payment & Shipping
Payment Methods:
Port of Shipment:
PORT OF SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
GIGA LX Paper Multiple Corrugation Machine SteamUS$ 6,000 - 9,000MOQ: 1 Set -
Automatic Carton MachineryNegotiableMOQ: 1 Set
-
GIGA LX Fully Computerized Corrugated Carton Box Cutting MachineUS$ 180,000 - 400,000MOQ: 1 Set
-
GIGA LX Manul Corrugated Cardboard Cutting Machine Chain Feeder PriceUS$ 30,000 - 85,000MOQ: 1 Set
-
GIGA LX Roll Paper Multiple Corrugation Machine SteamUS$ 6,000 - 9,000MOQ: 1 Set
Condition
New
Plate Type
Letterpress
Place of Origin
Shanghai, China
Brand Name
GIGA LX
Model Number
LX-308
Usage
Card Printer, Other, Card Printer, corrugated cardboard printer, Flexo printing, making carton
Automatic Grade
Automatic
Voltage
380V
Gross Power
50-70kw
Dimensions(L*W*H)
12*6.5*2.8m
Weight
28-30tons
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Flexo Carton Box Cutting Machine1.Servo control Lead edge feeder
2.999order memory
3. easy operate
LX-308 Automatic Flexo Printer Slotter & Die Cutter
Flexo Carton Box Cutting Machine Main Functions:
- Touch screen and electric control dual system
- All transmission gears are made of high quality alloy steel (20CrMnTi) grinded under high temperature with hardness HRC58-62
- CAPT-LOCKS union link to reduce the connect interval and keep long lasting overprint precision
- Functions of intelligent zero returning and memory reset 999 order memory
- Suitable for small and middl-big size carton
- The transmission system adopts two oil pumps circulating lubrication
Feeding Unit
- Servo control Lead edge feeder--patent #ZL2005 2 0045628.x (Back-pushing suck blower feeding system is option);
- Servo motor-quick react, precision positioning, system stability and durability. Electrical camshaft supersedes mechanical style;
- Synchronous belt un-interval links feeding shaft with servo motor shaft, to improve feeding precision alignment; Half-wheel, quick replacing structure, to keep consistency of feeding position, and to avoid uneven wearing on the surface of feeding wheel;
- Pressure-free stretching feeding mechanism is the option;
Printing Unit
- Carton box making machine forme roller and pressure roller are made of high quality steel, with grinded and chrome plated surface
- Dynamic and static balancing make steadily running; Hanging forme, make installation easy and quick; Forme changing both foot switch, and/or electric control (forward / backward run)
- Printing machine anilox roller auto lifting device synchronous working with paper feeding system (In feeding,lx308 anilox roller pressed whereas in stop, it released); Planetary gear phasing structure; Printing phase automatic 360 degree adjust by PLC, touch screen and motorized digital control.
- Electromagnetic clutch printing phase braking mechanism.
Slotting Unit
- Upper scoring wheel coated by polyurethane to avoid possible crush on the paperboard
- Transverse movement of scoring wheel, lx308 doctor wheel and slotting head controlled by motorized button control, easy and quick
- 7 mm thick slotting knives are made of alloy tool steel by heat treatment and finely ground, sharpened endurable teeth
- Bi-plate trimming knives with sharpened, endurable teeth.
- Planetary gear slot phasing structure .
- Aluminium hand hole punch device.
Die Cutting Unit
New adjusting system for die cutter, easy operation adjusting the error and the difference of die cutter'S cardboard.
Box making machine anvil roller and mould roller adopts high-grade steel with finely reground and chrome plated surface. Dynamic balancing correction enhances running stability
- Mould roller and anvil roller can be apart by the air cylinder eccentric mechanism during non-working condition in order to decrease the load of the machine and to prolong the life of the cutting mould and urethane rubber
- Mechanical drive anvil roller transverse moves up to ±30mm, lx308 installed with radial differential device, evenly spread/distribute abrasion to improve the life of anvil roller, unique speed difference compensation device makes a perfect die cutting .
Model |
1800/2200x1000 |
2500x1200/1400/1600 |
2800x1200/1400/1600 |
|
Max. machine speed (pcs/min) |
200 |
160/140/120 |
160/140/120 |
|
Max. printing speed(pcs/min) |
180 |
140/120/100 |
140/120/100 |
|
Max. feeding size(mm) |
1770/2170*970 |
2500*1170/1370 |
2500*1170/1370 |
|
Skip feeding size(mm) |
1770/2170*1170 |
2500*1370/1570/1770 |
2500*1370/1570/1770 |
|
Min. feeding Size(mm) |
650*280 |
650*380/400/450 |
700*380/400/450 |
|
Feeding depth (mm) |
2.5-10 |
2.5-10 |
2.5 - 10 |
|
Min. slot interval |
Positive cut (mm) |
120*120*120*120 |
140*140*140*140 |
140*140*140*140 |
|
Reverse cut (mm) |
190*50*190*50 |
250*80*250*80 |
250*80*250*80
|
|
Max. printing area(mm) |
1750/2150*950 |
2450*1150/1350 |
2750*1150/1350 |
|
Standard printing plate thickness(mm) |
7.2 |
7.2 |
7.2 |
|
*Subject to change and improvement without notice
