GIGA LX Used Flexo Slotting Die Cutting and Printing Machines

GIGA LX Used Flexo Slotting Die Cutting and Printing Machines thumbnail-1
GIGA LX Used Flexo Slotting Die Cutting and Printing Machines photo-1
US$ 130,000 - 400,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, Flexo
Place of Origin:
Shanghai, China
Contact Supplier Request Quote Chat Now
Shanghai Liu Xiang General Equipments Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Port of Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Other, Flexo
Place of Origin Shanghai, China
Brand Name GIGA LX
Model Number LX308
Usage Other, Making carton cardboard
Automatic Grade Automatic
Voltage 380V
Gross Power 30-45kw
Dimensions(L*W*H) 8000x7000x2200
Weight 9MT-25MT
Certification Got CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Touch-screen,Got CE
2.flexo printing machine
3.Memory order999 slotting machine
4.CNC adjusting system

LX308 Automatic Flexo Printing Slotting and Die Cutting Machine

flexo die cutting and printing machine

Main functions:



flexo printing machine

  1. Touch screen and electric control dual system lx308
  2. All transmission gears are made of high quality alloy steel (20CrMnTi) grinded under high temperature with hardness HRC58-62
  3. CAPT-LOCKS union link to reduce the connect interval and keep long lasting overprint precision
  4. Functions of intelligent zero returning and memory reset 999 order memory
  5. Suitable for small and middl-big size carton and many order change
  6. The transmission system adopts two oil pumps circulating lubrication
  7.  Flexo printing machine and box machine are made in very good quality.

We provide loan to below business situation
1. The value of order over RMB 1 million (including 1 million).
2. Only for boxing machine LX308N; LX608CN; LX707N or corrugated machine production line include LXC-180NN, LXC-220H1.8N models.
3. We accept O/A (Open account), it based on the credit level of buyer's bank credit report.
4. The details please consult with our sales department.





Feeding Unit

  1.  Servo control Lead edge feeder--patent #ZL2005 2 0045628.x (Back-pushing suck blower feeding system  is option);GIGA LX used flexo slotting die cutting and printing machines
  2. Servo motor-quick react, lx308precision positioning, system stability and durability. Electrical camshaft supersedes mechanical style;
  3. Synchronous belt un-interval links feeding shaft with servo motor shaft, to improve feeding precision alignment; Half-wheel, quick replacing structure, to keep consistency of feeding position, and to avoid uneven wearing on the surface of feeding wheel;
  4. Pressure-free stretching feeding mechanism is the option;



Printing Unit

  1. Box machine forme roller and pressure roller are made of high quality steel, with grinded and chrome plated surface, Dynamic and static balancing make steadily running, Hanging forme, make installation easy and quick, Forme changing both foot switch, and/or electric control (forward / backward run), Anilox roller auto lifting device synchronous working with paper feeding system (In feeding, anilox roller pressed whereas in stop, it released)
  2. Planetary gear phasing structureGIGA LX used flexo slotting die cutting and printing machines
  3. Printing phase automatic 360 degree adjust by PLC, touch screen and motorized digital control.  Forme roller intelligent zero returning, short cut resetting under dynamic and static condition
  4.  Motorized adjusts digital display the transversal position of the forme roller, up to 20 mm

Slotting Machine Unit

  1. Pre-scoring wheel: Pre-scored paperboard will not crush
  2. Upper scoring wheel coated by polyurethane to avoid possible crush on the paperboard
  3. Transverse movement of scoring wheel, doctor wheel and slotting head controlled by motorized button control,  lx308easy and quick
  4. 7 mm thick slotting knives are made of alloy tool steel by heat treatment and finely ground, sharpened endurable teeth
  5. Aluminium hand hole punch device.

GIGA LX used flexo slotting die cutting and printing machines



Die Cutting Unit  (new die-cutting technology)

  1. New CNC difference adjusting system for rotary die cutting,
  2. Adjusting the error and difference of die-cutter's Cardboard,
  3. Easy operation
  4. Anvil roller and mould roller adopts high-grade steel with finely reground and chrome plated surface.  Dynamic balancing correction enhances running stability
  5.  Mould roller and anvil roller can be apart by the air cylinder eccentric mechanism , to decrease the load of the machine and to prolong the life of the cutting mould and urethane rubber
  6. Mechanical drive anvil roller transverse moves up to ±30mm, and installed with radial differential device, to improve the life of anvil roller
  7. Unique speed difference compensation device makes the anvil roller slide together  to make a perfect die cutting



GIGA LX used flexo slotting die cutting and printing machinesGIGA LX used flexo slotting die cutting and printing machinesGIGA LX used flexo slotting die cutting and printing machines

Stacking Unit

  1. Connection arm has manual and automatic operation methods
  2. Tension of the driving belt of connection arm can be adjusted alone; quantity of connection arms can be set at will
  3. Platform elevation and transmission motor has braking function,
  4. A pneumatic controlled plate, Anti slipping belt used in the transport bed   lx307

Model

1800/2200x1000

2500x1200/1400/1600

2800x1200/1400/1600

Max. machine speed (pcs/min)

200

160/140/120

160/140/120

Max. printing speed(pcs/min)

180

120

120

Max. feeding size(mm)

1770/2170*970

2500*1170/1370

2500*1170/1370

Skip feeding size(mm)

1770/2170*1170

2500*1370/1570/1770

2500*1370/1570/1770

Min. feeding Size(mm)

650*280

650*380/400/450

700*380/400/450

Feeding depth (mm)

2.5-10

2.5-10

2.5 - 10

Min. slot interval

Positive cut

(mm)

120*120*120*120

140*140*140*140

140*140*140*140

Reverse cut

(mm)

190*50*190*50

250*80*250*80

 250*80*250*80



Max. printing area(mm)

1750/2150*950

2450*1150/1350

2750*1150/1350

Standard printing plate thickness(mm)

7.2

7.2

7.2

*Subject to change and improvement without notice,
