Specifications of 400kW Googol Natural Gas Power Plant
500kVA 400kW Natural Gas Power Generation Generator 60Hz 1800RPM RTA1340G2 Gas Engine 10 Cylinders V type Alternator Meccalte
| Engine Model | RTA1340G2 | |
| Rating Speed | rpm | 1800 |
| Frequency | Hz | 60 |
| Generator Output (COP) | kW | 400 |
| Power Factor | 0.8 | |
| Gas Engine Parameter | ||
| Engine Output (COP) | kW | 438 |
| Air Ratio | λ | 1.7 |
| Configuration | 12 Vee | |
| Displacement | l | 21.9 |
| Bore | mm | 128 |
| Stroke | mm | 142 |
| Compression Ratio | 12:1 | |
| Piston Speed | m/s | 8.52 |
| Number of Flywheel Teeth | 160 | |
| Flywheel House Size | SAE1-14 | |
| System Parameter | ||
| Oil Capacity | l | 90 |
| Max. Allowed Oil Temperature | °C | 110 |
| Oil Pressure Warning | kPa | 200 |
| Oil Pressure Shutdown | kPa | 160 |
| Coolant Capacity for Engine | l | 44 |
| Max. Coolant Warning Temperature | °C | 90 |
| Max. Coolant Shutdown Temperature | °C | 95 |
| Max. Intercooler Outlet Temperature | °C | 50 |
| Flow of Coolant pump (JW) | m³/h | 30 |
| Flow of Coolant pump (LT) | m³/h | 14 |
| Max. Exhaust Temperature | °C | 535 |
| Exhaust Flow | kg/h | 1708 |
| Exhaust Flange Diameter | mm | 2*125 |
| Charging Alternator Capacity | A | 35 |
| Starting Voltage | V | 24 |
| Thermal Balance | ||
| JW Coolant Heat | ±8% kW | 226 |
| CAC Intercooler Heat | ±8% kW | |
| Exhaust Heat up to 120°C | ±8% kW | 272 |
| Energy Input | kW | 1078 |
| ELectrical Efficiency | % | 37.1 |
| Mechanical Efficiency | % | 39.2 |
| Thermal Efficiency | % | 46.2 |
| Total Efficiency | % | 83.3 |
| Gas Consumption | MJ/kWh | 9.70 |
| Generator Parameter | ||
| Generator Model | ECO40-2S/4 | |
| Generator Prime Output | kW | 432 |
| Generator Efficiency @ 0.8PF | 94.7% | |
| Genset Dimension | ||
| Length | mm | 3600 |
| Width | mm | 1500 |
| Height | mm | 2000 |
| Genset Weight | kg | 4300 |
4. Governor System: Governor controller, Throttle, Sensor,
5. Detonation System: Detonation controller, Sensor
6. Cut off valve, Pressure regulator, Flame arrester
7. Gas Train: Cut-off Valve, Gas filter, Gas Regulator, Gas Control Valve
8. NOx Emission @ 100% load ≤500mg/Nm3
9. Gas Low Heat Value: ≥ 36MJ/Nm3
Applied Gas:
Natural Gas, Biogas, City Sewage Gas, Landfill gas, Oil gas, farm biogas, Coal mine gas,etc
Acceptable fuel gas pressure: 5~12kPa
CH4 content: for natural gas≥85% CH4 ,content:for biogas≥40%
Gas heat value≥5500kcal/Nm3 (23MJ/Nm3 ). Genset output power will increase as the gas heat value increase, if use low heat value gas for fuel (Heat value<5500kcal/Nm3, it will lower the power efficiency.
Gas doesn’t include free water or free materials (the size of impurities should be less than 5μm.)
H2S content≤200mg/Nm³
NH3 content≤20mg/Nm³
Impurities content≤30mg/Nm³;size≤5μm
Water content≤40g/Nm³, no free water.
Acceptable working conditions:
Ambient temperature : -10°C~+40°C
(antifreeze or preheater needed for below 0°C)
Relative humidity:<90%(20°C)
Altitude:≤1000m
Normal working conditions:
Genset can run at rated power on the conditions:
Atmospheric Pressure: 100kPa, Ambient Temp: 20°C, Relative Humidity: 30%.
As a more than 10 years generator supplier, we have advantages as follow:
1) Professional diesel generator manufacturer, not trader.
2) Decades’ years of manufacturing and exporting experience.
3) Adopt International quality standards, to meet high quality requirement.
4) Good reputation for Reliable quality & Reasonable price.
5) Strong technical support.
6) Advanced production line with skilled workers.
We have built cooperation with world famous engine maker and alternator makers:
We attend famous trade shows every year:
Some generators for your reference:
FAQ:
1. What is your warranty period?
--1 year or 1500 running hours as standard warranty.
2. Does your generator have global warranty?
--Yes, most of our products like Cummins, Perkins, Doosan, Yuchai, Deutz, Volvo power generator enjoy the global warranty service. And the alternator we use like Leroysomer, Stamford, marathon also enjoy the global warranty service, so you do not need to worry about the aftersales service.
3. Can you accept OEM?
--Yes.
4. What is your payment terms?
--We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight, L/C deferred payment terms or west union.
5. What is your delivery time?
--Our normal delivery time is 15-20 days. But if your order is some special engine and alternator, then the delivery time is longer.
