Environment friendly 150kw natural gas generator with Cummins engine

FOB Price

USD $30,000 - $31,000 / Set

1 Set(Min.Order)

Supply Ability 200 Set / Sets per Month
Port Qingdao
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	SUPERMALY
Model Number	SPC150GF-T	Output Type	AC Three Phase
Speed	1500RPM/1800RPM	Frequency	50/60HZ
Rated Power	150kw	Rated Voltage	400V
Rated Current	270A

Product Description

1. 150kw natural gas generator feature

1) 150kw natural gas generator gas consumption: 0.28Nm³/kw.h

2) 150kw natural gas generator running cost lower.

3) 150kw natural gas generator can be installed on your site.

4) We supply you spare parts during the whole service life for 150kw natural gas generator.

5) 150kw natural gas generator adopt Cummins engine block, the quality is very strong. Also it is easy for customer to get maintenance spare parts.

6) 150kw natural gas generator adopt advanced Hall ignition sensor and highly quality USA Altronic ignition system, the engine ignition will be more reliable and easier to start. Besides,there is Top End Center mark on the engine,it is easy for users to adjust the top end certer when commissioning generator set.

7) 150kw natural gas generator adopt ComAp or Deepsea Interligen/Interlisys controller to make synchronization for generator set, all the parameters can be set in the program and can realize the remote controlling through cell phone or computer.

8) The gas inlet pressure for 150kw natural gas generator is 2~7kPA.

9) 150kw natural gas generator with electrical mixer. The mixer guarantees optimum air-fuel ratio to improve efficiency and reduce NOx emission. Unique air-fuel ratio adjusting system is suitable for 30%~90% methane concentration.

2. 150kw natural gas generator specification

150KW Natural Gas Generator
Genset Model		Open Type	SPC150GF-T
Prime Power (kW)			150
Standby Power (kW)			165
Rated current (A)			270
Overall Size(mm)		Length(mm)	3000
		Width(mm)	1200
		Height(mm)	1700
Gross Weight(kg)			2800

Gas Engine	Model		SPCNTAA
	Brand		Cummins brand
	Type		water-cooled, 4-stroke, spark plug ignition
	Rated Power(kW)		165
	Intake Type		Turbocharged intercooling
	No.of Cylinder		6.L
	Bore*Stroke(mm)		140*152
	Gas consumption(Nm³/kw.h)		0.3
	Lub oil Consumption(g/kw.h)		1.6
	Oil capacity		36.7L
	Displacement		14L
	Starting method		DC 24V Electric starter
	Governing Type		Electric governor
Alternator	Model		274G
	Brand		Stamford technology alternator
	Rated Power(kW)		150
	Voltage Regulation		±1
	Excitation Type		Brushless
	Insulation Class		H

3. Our advantage on 150kw natural gas generator

1. Professional metan gas generator manufacturer, with 35000 square meters factory.

2. Decades’ years of manufacturing and exporting experience

3. Adopt International quality standards and USA technology to meet high quality requirement

4. Good reputation for Reliable quality & Reasonable price

5. Strong technical support

6. Advanced production line with skilled workers

4. 150kw natural gas generator electrical feature

Voltage: 400/230V, 220/127V,440/254V, 480/277V, etc

Frequency: 50Hz/ 60Hz Speed: 1500r.p.m / 1800 r.p.m

Power Factor: 0.8(lagging)

Protection Standard: IP23

Model of Connection: 3 phase 4 lines /1 phase

Insulation Grade: H

Frequency Drop(%): ≤ 0.5

Transient state frequency deviation(%):(advertised power ) +10~-7

Frequency Recovery Time(S): ≤ 3

Voltage Recovery Time(S): ≤4

Waveform Distortion(%): ≤5

1. Our 150kw natural gas generator powered by Cummins engine, Yuchai engine, Deutz engine, or China engine.

2. Our 150kw natural gas generator exported to all over the world, with low gas consumption, easy operation, overhall time more than 25000hours.

photos of generators

5. 150kw natural gas generator photos

Detailed parts photo of 150kw natural gas generator

Gauge, Altronic ECU, IMPCO mixer, USA gas reducing valve

Test before delivery

Test before delivery for 150kw natural gas generator

Packaging & Shipping

Packaging and shipping of 150kw natural gas generator

If there is any problem, pls contact with me by email or online. Thanks.

+Whatapp / + viber : +86 15095247272
