Introduction of rotary dryer:
it can accept almost all kinds of materials and can quick drying the materials. It is easy to operate and has large capacity. that is why this machine is so welcomed in every field.
2. Working principle of rotary dryer
The raw material plate is arranged conveniently to allow adjustable angle positions.
The material to be dried is inserted to the rotary cylinder through the raw material plate.
Hot air flows within the cylinder causing the separation of water from the material by
converting it into vapor which is discharged into the atmosphere.
At this point, the material becomes dry.
The dryer is formed by stove, rotary body, raising plate, feeder, driving device, supporting device and sealing ring, cylone and fan.
Technical Parameters:
Model (mm) |
Speed(r/min) |
Slope(%) |
Inlet Air Temperature(°C) |
Power(kw) |
Capacity(t/h) |
Weight(t) |
800×8000 |
3-8 |
3-5 |
≤700 |
4 |
0.8-2 |
3.5 |
1000×10000 |
3-8 |
3-5 |
≤700 |
5.5 |
1-3 |
5.6 |
1200×10000 |
3-8 |
3-5 |
≤700 |
7.5 |
2-3.5 |
13.5 |
1200×12000 |
3-8 |
3-5 |
≤700 |
11 |
2.5-4 |
14.2 |
1500×12000 |
2-6 |
3-5 |
≤800 |
11 |
4-6 |
18.5 |
1500×15000 |
2-6 |
3-5 |
≤800 |
18.5 |
5-8 |
21 |
1800×18000 |
2-6 |
3-5 |
≤800 |
18.5 |
6-12 |
31 |
2000×18000 |
1.5-6 |
3-5 |
≤800 |
22 |
8-15 |
35 |
2200×12000 |
1.5-6 |
3-5 |
≤800 |
22 |
13-15 |
31.6 |
2200×14000 |
1.5-6 |
3-5 |
≤800 |
22 |
14-16 |
33.5 |
2200×16000 |
1.5-6 |
3-5 |
≤800 |
30 |
14-18 |
36 |
2400×18000 |
1.5-6 |
3-5 |
≤800 |
45 |
16-22 |
42.8 |
2400×20000 |
1.5-6 |
3-5 |
≤800 |
45 |
18-25 |
52 |
3000×20000 |
1.5-6 |
3-5 |
≤800 |
55 |
25-30 |
77.8 |
3000×25000 |
1.5-6 |
3-5 |
≤800 |
55 |
28-34 |
87.5 |
The delivery of rotary dryer:
rotary dryer at plant site:
Certification and honors:
Our factory:
