Good sale rotary dryer / coal slime dryer
Introduction of rotary dryer / coal slime dryer:
Rotary dryer is a type of drying machine used to reduce the moisture of raw material, it is widely applied in building materials, metallurgy, chemicals, coal, fertilizer, sawdust industrials. it can accept almost all kinds of materials and can quick drying the materials. It is easy to operate and has large capacity. that is why this machine is so welcomed in every field.
1. Features of rotary dryer / coal slime dryer :
1.Wide applicability, available for many kinds of materials.
2.Simple operation, stable performance;
3.Low investment, high efficient and capacity;
4.Low cost in maintenance
2. Working principle of rotary dryer / coal slime dryer :
The raw material plate is arranged conveniently to allow adjustable angle positions. The material to be dried is inserted to the rotary cylinder through the raw material plate. Hot air flows within the cylinder causing the separation of water from the material by converting it into vapor which is discharged into the atmosphere. At this point, the material becomes dry.
the dryer is formed by rotary body, raising plate, driving device, supporting device and sealing ring.
3. Application of rotary dryer / coal slime dryer:
This dryer can dry many kinds of materials which contain moisture, such as coal, coal slurry, slag, industrial waste, charcoal power/dust, sawdust, copper powder, compound fertilizer and clay stone. They are widely used in building materials, metallurgy, and chemical industry.
4.Technical Parameters of rotary dryer / coal slime dryer:
Model (mm) |
Speed(r/min) |
Slope(%) |
Inlet Air Temperature(°C) |
Power(kw) |
Capacity(t/h) |
Weight(t) |
800×8000 |
3-8 |
3-5 |
≤700 |
4 |
0.8-2 |
3.5 |
1000×10000 |
3-8 |
3-5 |
≤700 |
5.5 |
1-3 |
5.6 |
1200×10000 |
3-8 |
3-5 |
≤700 |
7.5 |
2-3.5 |
13.5 |
1200×12000 |
3-8 |
3-5 |
≤700 |
11 |
2.5-4 |
14.2 |
1500×12000 |
2-6 |
3-5 |
≤800 |
11 |
4-6 |
18.5 |
1500×15000 |
2-6 |
3-5 |
≤800 |
18.5 |
5-8 |
21 |
1800×18000 |
2-6 |
3-5 |
≤800 |
18.5 |
6-12 |
31 |
2000×18000 |
1.5-6 |
3-5 |
≤800 |
22 |
8-15 |
35 |
2200×12000 |
1.5-6 |
3-5 |
≤800 |
22 |
13-15 |
31.6 |
2200×14000 |
1.5-6 |
3-5 |
≤800 |
22 |
14-16 |
33.5 |
2200×16000 |
1.5-6 |
3-5 |
≤800 |
30 |
14-18 |
36 |
2400×18000 |
1.5-6 |
3-5 |
≤800 |
45 |
16-22 |
42.8 |
2400×20000 |
1.5-6 |
3-5 |
≤800 |
45 |
18-25 |
52 |
3000×20000 |
1.5-6 |
3-5 |
≤800 |
55 |
25-30 |
77.8 |
3000×25000 |
1.5-6 |
3-5 |
≤800 |
55 |
28-34 |
87.5 |
Different Models of our rotary dryer:
Our certification and honors:
Factoy and application site:
Our Company Introduction:
Gongyi Hengchang Metallurgy Building Material Equipments plant was built in 1992, is a professional manufacturer specializing in the production of mineral beneficiation equipments, sand and stone crushing equipments, briquetting equipments, coal preparation equipments, drying and calcining equipments, cement plant equipments and compound fertilizer equipments. The products are widely used in mineral processing, metallurgy, building materials, chemicals, electricity, petroleum, coal, transportation, fertilizer , gas industry etc.
