Specifications
1. Electric laboratory furnace2.Big factory direct supply
3.Latest technique
4.1 year warranty
5.CE approved
1400 type Shaft furnace (SJL-1400)
Products Introduce:
SJL- 1400 shaft furnace adopted the top open type door, with silicon carbide rod as heating elements, and with double shell structure and intelligent temperature control system. Furnace chamber adopted polycrystalline alumina fiber material, excellent heat preservation and energy saving.
Main function and features:
1. Furnace chamber adopted imported alumina polycrystalline fiber, with good insulation and durability properties; And adopted the imported silicon carbide rod as heating elements, greatly improving the service life;
2. Adopted top open door structure, power cutoff automatically when open the door;
3. Reserved 485 converter interface, can remote control of single or multiple furnace through software and Internet, real-time tracking , history recorder, output statements ; can install the paperless recording device for data storage and output;
4. Over-temperature alarm and power failure, leakage protection, safe and reliable operation.
Main applications:
Tempering, annealing and other heat treatment of metal materials and aluminum, light alloy hardening, solid solution treatment, aging treatment and other experiments.
Technical parameters:
Model |
SJL-1400 (Approved by CE certificate, ensure the safety operation of the machine. Certificate No.: GB/1067/4189/12 Issue 1) |
Furnace chamber size |
300*250*200mm (Customizable) |
Door structure |
Top open type |
Temperature control mode |
The temperature control system uses artificial intelligence technology, with PID control, self - tuning function, 50 the heating and cooling program |
Heating elements |
Imported Silicon carbide rod |
Thermometric component |
S-mode thermocouple |
Power supply |
≤1300°C |
Max. temperature |
1350°C |
Constant temperature accuracy |
±1°C |
Recommend heating rate |
10°C/min |
Rated power |
6KW |
Power supply |
AC220V 50HZ/60HZ |
Packing :Plywood box with foam
