Help CenterMedium-Range Flexographic Press(FM830/900/1000/1100)
Related Products
-
Three-dimensional Type of Non-woven Straight-up Bag-making Machine(FM-A500/800)NegotiableMOQ: 1 Set -
FM-A500/800 Non-woven Straight-up Bag-making MachineNegotiableMOQ: 1 Set
-
Roll-fed Square Bottom Paper Bag Machine(FM-FJ11C)NegotiableMOQ: 1 Set
-
Servo Series of MechanicalNegotiableMOQ: 1 Set
-
Servo Drive SeriesNegotiableMOQ: 1 Set
Specifications
can realize dusting, corona, printing, die-cutting, indentation, drilling, waste discharge, cut off flat papers
Applicable objects: environmental protection printing and packaging industry, such as food, medical, industries such as paper bags, paper boxes, paper cups, boxes printed printing processing.
Scope of application: applicable to the kraft paper, cardboard, coated paper, paper liner, multi-layer composite paper, non-woven fabrics and other printed materials.
Main features:
1, can realize dusting, corona, printing, die-cutting, indentation, drilling, waste discharge, cut off flat paper, such as cutting attachment processing capacity.
2, the use of water-based ink or UV ink, belong to the environmental protection printing.
3, using ceramic anilox roller, ink evenly, long service life.
4, hot air drying, infrared drying, UV curing (UV drying) can free choice.
5, closed loop tension control, tension stable printing, set accurately.
6, automatic electronic correction system.
7, printing rules on-line detection.
8, automatic horizontal alignment manually can be free to choose
| Specification | 13"(330) | 16.5"(420) | 20.5"(520) | 25.5"(650) |
| Max. Web Width | 340mm | 430mm | 530mm | 660mm |
| Max. printing width | 330mm | 420mm | 520mm | 650mm |
| Max. Die-cutting width | 330mm | 420mm | 520mm | 650mm |
| Impression plate repeat length | 190--650mm | 190--650mm | 190--650mm | 190--650mm |
| Die-cutting Repeat length | 190--650mm | 190--650mm | 190--650mm | 190--650mm |
| Max. Unwind Diameter | 1067mm | 1524mm | 1524mm | 1524mm |
| Max. Rewind Diameter | 1067mm762mm | 1524mm762mm | 1524mm762mm | 1524mm762mm |
| Print cylinder Gearing | 1/8cp | 1/8cp | 1/8cp | 1/8cp |
| Max printing speed | 150m/min | 150m/min | 150m/min | 150m/min |
| Diameter of web roller | 75mm | 75mm | 75mm | 75mm |
| Main motor power | 11kw | 11kw | 11kw | 11kw |
| Drying mode | a. Warm Drying b. IR Drying c. UV Drying | |||
| Ink used | a. Water base ink b. UV ink | |||
| Power Requirement | 380V 3PH 50Hz | 380V 3PH 50Hz | 380V 3PH 50Hz | 380V 3PH 50Hz |
| Suitable for material | 17g copy paper, tissue paper 80-450g copperplate paper Aluminium foil, BOPP,PET,paper board,Kraft paper |
|||
