AIR FORGING HAMMER C41-75KG
- 30 Set / Sets per Month
- QINGDAO/SHANGHAI/YIWU/GUANGZHOU/TIANJIN
- T/T
You May Like
Product Details
Condition | New | Place of Origin | Shandong, China | |
Brand Name | HELI | Model Number | C41-75 | |
Voltage | 380V/415V/440V/480V | Power(W) | 7500 | |
Dimension(L*W*H) | 1400 X 760 X 1950 MM | Weight | 2700 KG | |
Certification | CE ISO | Warranty | 12 months | |
After-sales Service Provided | No overseas service provided |
Product Description
Pneumatic forging hammer is widely used for general forging works, such as drawing-out, upsetting, punching, chiseling, forging, welding, bending and twisting. It is also used for forge in bolster dies. Air hammer is also called forging hammer, blacksmithing hammer, pneumatic forging hammer, power hammer and so on. Air hammer falling weight at 6kg, 16kg, 20kg, 25kg, 40kg, 55kg, 75kg, 150kg, 250kg mainly for artistic wrought iron, artistic forging, blacksmith, agriculture tools and small open die forging parts.
All our air hammer are professional produced from the source of material,even one bolt and screw,we always choose the best and durable for our hammer.Only with strong hammer body frame and hardened ,durable parts,that can make the hammer more stable,druble and high efficent.Of course,you must be familar with all our hammer from our operation manual.
All of hammer are test about 72 hours on the trial bench to make sure every hammer are running well.
If find any little defect,pls feedback to our after sale service,we would make record down them and then feedback to our technical
department and then give the improvement and solution at first time.
So no matter what problem or questions you have,pls contact with us,we would reply you within 24 hours.
TECHNICALSPECIFICATIONS | |||||||||||||
No. | Name. | Unit | C41-6 | C41-16 | C41-20 | C41-25 | C41-40 | C41-55 | C41-75 | C41-150 | C41-250 | ||
1 | Weight of falling parts | Kg | 6 | 16 | 20 | 25 | 40 | 55 | 75 | 150 | 250 | ||
2 | Max. hit energy | Kj | 0.066 | 0.18 | 0.22 | 0.27 | 0.53 | 0.7 | 1 | 2.2 | 5.6 | ||
3 | Hit number | min -1 | 248 | 258 | 255 | 250 | 245 | 230 | 210 | 180 | 150 | ||
4 | Distance from bottom die surface to bottom surface of lead | mm | 175 | 180 | 200 | 215 | 245 | 295 | 300 | 370 | 450 | ||
5 | Tup axis to hammer body | mm | 100 | 150 | 180 | 200 | 235 | 280 | 300 | 360 | 430 | ||
6 | Dimension of top and bottom die surface | mm |
| 70x40 | 90x50 | 100x50 | 120x50 | 120x55 | 145x65 | 200x85 | 220x100 | ||
7 |
Maximum forge | Round piece | mm |
| 22 | 35 | 45 | 68 | 68 | 85 | 145 | 175 | |
Square piece | mm |
| 20x20 | 30x30 | 40x40 | 52x52 | 52x52 | 65x65 | 130x130 | 145x145 | |||
8 | Distance from bottom die surface to base | mm |
| 307 | 407 | 436 | 555 | 568 | 746 | 735 | 750 | ||
9
|
Motor | Type |
|
|
|
|
|
|
|
|
| 180L-4 | |
Rate power | kw | 0.75 | 1.5 | 2.2 | 3 | 4 | 5.5 | 7.5 | 15 | 22 | |||
speed | r.p.m | 1440 | 1440 | 1440 | 1440 | 1440 | 1440 | 1440 | 1440 | 1470 | |||
10 | Overall dimension | mm | 480x340x670 | 660x420x970 | 820x460x1110 | 900x510x1200 | 1080x600x1430 | 1320x670x1620 | 1400x760x1950 | 2080x1240x2350 | 2875x1405x2570 | ||
11 | Anvil weight | Kg | ------- | --------- | 190 | 250 | 400 | 600 | 850 | 1800 | 2950 | ||
12 | Total weight | Kg | 126 | 240 | 500 | 760 | 1350 | 1700 | 2800 | 5060 | 8200 |
