Metal Forging Machine C41-20KG SINGLE WITH BASEPLATE

Metal Forging Machine C41-20KG SINGLE WITH BASEPLATE thumbnail-1
Metal Forging Machine C41-20KG SINGLE WITH BASEPLATE photo-1
Negotiable MOQ: 20 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
HELI
Contact Supplier Request Quote Chat Now
Tengzhou Runfa Machinery Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Shandong, China
Brand Name HELI
Model Number C41-20KG
Voltage 220V/380V/240V/415V
Power(W) 2.2KW/3KW
Dimension(L*W*H) 970X360X1250
Weight 460KG
Certification ISO9001:2008
Warranty 12 months
After-sales Service Provided No overseas service provided

Specifications

Air Hammer C41-20kg:
1.Reliable structure;
2.Easy-operation;
3.Stable function;
4.High precision

Metal Forging machine C41-20KG SINGLE WITH BASEPLATE

Item

Unit

Numerical Value

Weight of falling parts

kg

20

Maximum blow energy

J

220

Distance from center of die to frame

mm

180

Distance between top and bottom die

mm

200

Number of blows per minute

min-1

270

Dimension of top to bottom

mm

90*50

Diameter of the working cylinder

mm

150

Diameter of the compressing cylinder

mm

155

Travel distance of malleus

mm

200

Travel distance of plunger

mm

130

Forges

Round

mm

Φ35

Square

mm

30

Motor

Power

kw

2.0

Rotate speed

rpm

1440



Outside Size

Length

mm

970

Width

mm

360

High

mm

1250

Baseplate weight

kg

60

Hammer weight

kg

~460
