Home > Tools & Hardware > Pneumatic Tools > Pneumatic Wrench > Air Hammer C41-16KG

Air Hammer C41-16KG

Name: Air Hammer C41-16KG
Brand: HELI
SKU: 103158959
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

HELI

Model Number:

C41-16KG

Contact Supplier Request Quote Chat Now

Tengzhou Runfa Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name HELI

Model Number C41-16KG

Type Air Hammer

Specifications

AIR HAMMER is used for forging works,such as drawing-out,upsetting,punching,chiseling,forge,welding,bending and twisting.

This pneumatic forging hammer is widely used for general Forging works,such as drawing-out,upsetting,punching,chiseling,forge,welding,bending and twisting,it is also used for forge in bolster dies.

Item		Unit	Numerical Value
Weight of falling parts		kg	16	20	25	40	75
Maximum blow energy		J	180	220	270	530	900
Distance from center of die to frame		mm	150	180	200	235	300
Distance between top and bottom die		mm	180	200	240	245	300
Number of blows per minute		min-1	258	270	250	245	210
Dimension of top to bottom		mm	70*30	90*50	100*50	120*50	145*65
Diameter of the working cylinder		mm	115	150	165	200	235
Diameter of the compressing cylinder		mm	125	155	170	205	240
Travel distance of malleus		mm	210	200	275	290	345
Travel distance of plunger		mm	120	130	140	154	200
Forges	Round	mm		Φ35	Φ45	Φ68	Φ85
Forges	Square	mm		30	40	52	65
Motor	Power	kw	1.5	2.0	2.2	4.5	7
Motor	Rotate speed	rpm		1440	1440	1440	1440
Outside Size	Length	mm	584	670	800	1080	1600
	Width	mm	390	360	410	600	950
	High	mm	952	1050	1213	1389	1950
Anvil block weight		kg		190	247	400	850
Hammer weight		kg	~220	~500	~720	~1400	~2800
