CK518 single column cnc vertical lathe machine
Such cnc single column vertical lathe machine has following features:
1. single column vertical lathe;
2. CE Certificate and kinds of cnc controllers for your choice: Fanuc, Siemens, GSK and so on;
3. such vertical lathe is suitable for turning the ferrous, nonferrous metal and some kinds of non-metal materials with hard alloy, high capacity and high speed steel tools.
4.Main bodies of the machine are made of high rigid resin sand castings with thermal aging treatment. Steel parts are thermal refined.
5.The machine adopts a stable rigid structure and consists mainly of base, table, column, cross rail, tool head, hydraulic system and electric system. Cross rail moves up and down along guideways of the column.
6.Hydraulic system of the machine is adopted for table hydrostatic system, table speed change, ram balancing system, cross rail clamping & unclamping and lubrication system.
Specifications |
Unit |
CK518 cnc vertical turning lathe machine |
Max. turning diameter |
mm |
800 |
Work tale diameter |
mm |
720 |
Max. height of work piece |
mm |
800 |
Max. weight of work piece |
t |
1.2 |
Work table speed |
r/min |
10~315 |
Work table step |
steps |
16 |
Travel of cross beam |
mm |
580 |
Horizontal travel of tool post |
mm |
570 |
Vertical travel of tool post |
mm |
570 |
Max. cutting force of tool post |
N |
10000 |
Max. torque |
KNm |
6 |
Main motor power |
kW |
18 |
Weight of machine |
t |
8 |
Overall dimension of machine |
mm |
2080x2621x3535 |
kinds of colors for your choice/can be customized
No cover:
Semi-cover
