CK5250 Heavy CE double column cnc vertical lathe
- 100 Set / Sets per Month
- Dalian China
- T/T L/C D/P D/A
Product Details
Condition: | New | Type: | Vertical | CNC or Not: | CNC |
Automatic Grade: | Automatic | Max. Swing Diameter: | 5000mm | Place of Origin: | Liaoning, China |
Brand Name: | LFM | Model Number: | CK5250 cnc vertical lathe | Voltage: | 220V/360V/440V/480V |
Power(W): | 50kW | Dimension(L*W*H): | depends | Weight: | 30 tons |
Certification: | CE; ISO9001:2008; GB/T19001:2008 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
CK5250 Large cnc vertical lathe Technical Data
1. The CNC vertical lathe is of excellent performance, a wide range of technology, high productivity.
2. Based on referring to the advanced machine design and manufacturing technology, adopting the newest design philosophy, and combining the profound corporate culture, our company has developed a kind of delicate machine tools with mechatronics and hydraulics integration, and provided the world-class products for overseas and domestic customers.
3. To make the lathe with high turning precision and enough rigidity and intensity, the table adopts integral casting and thermal symmetric structure, the main shaft bearing is the high-precision double row cylindrical roller bearing, and the table guideway;
Specifications | Unit | Parameter |
Max. turning diameter of railhead | mm | 5000 |
Table diameter | mm | 4500 |
Max. working height of workpiece | mm | 2500 |
Max. weight of workpiece | T | 30 |
Travel of tool post Horizontal | mm | 2765 |
Max. cutting resistance of right tool post | N | 35000 |
Max. cutting resistance of left tool post | N | 28000 |
Max. torque of table | KN.m | 100 |
Speed range of table | r/min | 1.3~42 four gears stepless |
Power of main motor | kW | DC75 |
Rapid traveling speed of tool post | mm/min | 4000 |
Table guide |
| hydrostatic |
Moving degrees limit of tool post | ° | -15~+30 |
Controller |
| Siemens 802D or Optional |
Position accuracy | mm | Test and evaluate accuracy According to GB/T17421.2-2000 |
1)Positional accuracy | mm | X Z 0.03/1000 |
2)Repeatable positional accuracy | mm | X Z 0.015/1000 |
3)Reverse positional accuracy | mm | X Z 0.010/1000 |
Temperature range | ° | 0~40° |
Ambient thumidity |
| ≤85% |
Power supply and voltage |
| 380V±10% |
Span of two guideways of the column | mm | 450 |
Travel of tool post (Vertical) | mm | 1000 |
Number of feeds |
| Stepless |
Feed range of table | mm | 0.05~2000 |
Vertical travel of crossbeam | mm | 2150 |
Moving speed of crossbeam | mm/min | 410 |
Power of motor for going up and down of crossbeam | kW | 11/18.5 |
Net Weight | T | 30 |
kinds of colors for your choice/can be customized
