C5116 CE single column conventional vertical lathe for sale
- 100 Set / Sets per Month
- Dalian/Tianjing/Shanghai/Qingdao China
- T/T Credit Card PayPal
Product Details
Condition: | New | Type: | Vertical | CNC or Not: | Normal |
Automatic Grade: | Semi-Automatic | Max. Swing Diameter: | 1600mm | Place of Origin: | Liaoning, China |
Brand Name: | LFM | Model Number: | C5116 single column vertical lathe | Voltage: | Customer's Requirement |
Power(W): | 22/30kW | Dimension(L*W*H): | 3000*3000*3450mm | Weight: | 12.5 tons |
Certification: | CE Certificate; ISO9001:2008; GB/T19001:2008 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
C5116 conventional single column vertical lathe
Such vertical lathe has following features:
suitable of the ferrous, nonferrous metal and some kinds of non-metal materials with hard alloy, high capacity and high speed steel tools.
1. The single column vertical lathe is a super rigid lathe with big machining capacities, stable structure and high machining efficiency.
2.The lathe is equipped with one vertical tool head with one ram.
3. The lathe machines are designed and built to meet modern machining requirements of high speed steel cutters and carbide cutters on workpieces of ferrous, non-ferrous, composite and other materials.
4. The vertical lathe can finely and roughly for
- I.D. & O.D. cylindrical turning,
- end-facing,
- I.D. & O.D. cone turning,
- grooving,
- boring, drilling, reaming, etc.
5. Lathe Body
Main bodies of the lathes are made of high rigid resin castings with thermal stress relief aging treatment. Small cast iron bodies are hardened with high temperature. All the steel parts are thermal refined.
6. Lathe Structure
High torque AC 22 kW main motor for vertical turret lathe model C5116 is adopted for driving the table through gear box. 16 speeds are achieved on the table. Double row cylindrical roller bearing is equipped under the table. The cone inner ring of the bearing can eliminate the radial clearance effectively for high precision and stable machining at high speed.
7. Hydrostatic Working Table of Vertical Lathe
Hydrostatic table is adopted with constant flow synchronous pumps. It features:
a). low friction for permanent life of table,
b). heavy load capacity on table,
c). oil film between machine base an d table absorbscutting vibration & loads,
d). a safety system controls the hydrostatic pressure for optimum safety.
8. with DRO and CE Certificate;
Specifications | Unit | Parameter |
Max. turning diameter | mm | 1600 |
Max. working height | mm | Standard: 1000 Optional: 1200/1400/1600 |
Max. weight of workpiece | T | 5 |
Table diameter | mm | 1400 |
Speed range of table | r/min | 5~160 |
Speed-step of table |
| 16 |
Max. torque of table | KN.m | 25 |
Max. cutting resistance of railhead | KN | 25 |
Max. cutting resistance of side head | KN | 20 |
Total cutting resistance | KN | 40 |
Travel of railhead (Horizontal) | mm | 915 |
Travel of railhead (Vertical) | mm | 800 |
Travel of side head (Horizontal) | mm | 630 |
Travel of side head (Vertical) | mm | 900 |
Travel of crossbeam | mm | 650/850/1050/1250 |
Feed range of railhead and side head | mm/min | 0.8~86 |
Rapid moving speed of railhead and side head | mm/min | 1800 |
Moving degrees limit of railhead |
| ±30° |
Moving speed of crossbeam | mm/min | 440 |
Power of main motor | kW | 22 |
Overall dimensions (L×W×H) | mm | 2830×2670×2810 3010×2670×2810 3210×2670×2810 3410×2670×2810 |
Weight of machine | T | 12.5 |
kinds of colors for your choice/can be customized
