Home > Manufacturing & Processing Machinery > Machine Tools > Milling Machine > S Series CE Bed Type Cnc Vertical Milling Machine

S Series CE Bed Type Cnc Vertical Milling Machine

S Series CE Bed Type Cnc Vertical Milling Machine photo-1

S Series CE Bed Type Cnc Vertical Milling Machine photo-2

US$ 27,580 - 53,971 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Liaoning, China

Brand Name:

LFM

Contact Supplier Request Quote Chat Now

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian/Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Liaoning, China

Brand Name LFM

Model Number S1354B/S1654/S2063/S2063A/S2473 cnc vertical milling machine

Type Vertical

CNC or Not CNC

Voltage 220V 380V 400V 415V 440V 480V

Power(W) 5.5/7.5kW

Dimension(L*W*H) depends

Weight 3400~7500kgs

Certification CE Certificate; ISO9001:2008; GB/T19001:2008

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

S series CE bed type cnc vertical milling machine

Brief Introduction

1. Main parts are original from TAIWAN;
2. GERMANY technology, main technology guided by GERMANY engineer;
3. Providing machine as OEM form for GERMANY Company as long term;
4. Full production is supervised by TAIWAN engineers;
5. Strictly according to CHINA National Standard and CE Safety Standar;

6. CE Certificate;

Main Technical Data

Specifications	Unit	S1354B	S1654	S2063	S2063A	S2473
Table size (L × W)	mm	1370×330	1370×406	1600×510	1600×510	1854×610
Table loading capability	kg	400	800	1200	1200	1500
X Travel	mm	800	1000	1200	1200	1500
Y Travel	mm	450	480	700	740	740
Z Travel	mm	480	600	600	740	700
Max. move speed(X/Y/Z)	mm/min	8000	8000	10000	10000	10000
Max. feed speed(X/Y/Z)	mm/min	3000	3000	4000	4000	4000
Spindle speed range	r/min	40~6000	40~6000	40~6000	40~6000	40~6000
Spindle taper		BT40	BT40	BT40/BT50	BT40/BT50	BT40/BT50
Spindle motor power	kW	5.5	7.5	7.5	7.5	7.5
X/Y/Z servo motor power	kW	1.5	1.5	2.8	2.8
Spindle quill diameter	mm	Φ120	Φ150	Φ150/Φ155	Φ150/Φ155	Φ150/Φ155
Distance from spindle nose end face to table surface	mm	60~640	80~680	60~660	60~800	80~780
Ball screws (X axis)	mm	Φ32×5 P4 Double nuts	Φ32×5 P4 Double nuts	Φ40×10 P4 Double nuts	Φ40×10 P4 Double nuts	Φ40×10 P4 Double nuts
Ball screws (Y axis)	mm	Φ32×5 P4 Double nuts	Φ40×5 P4 Double nuts	Φ40×10 P4 Double nuts	Φ40×10 P4 Double nuts	Φ40×10 P4 Double nuts
Ball screws (Z axis)	mm	Φ32×5 P4 Double nuts	Φ40×5 P4 Double nuts	Φ40×10 P4 Double nuts	Φ40×10 P4 Double nuts	Φ40×10 P4 Double nuts
Positioning accuracy	mm	0.025	0.03	0.03	0.03	0.04
Repeat positioning accuracy	mm	0.012	0.016	0.016	0.016	0.020
Packing dimension (Semi-closure guard) (L × W × H)	mm	2280×2250×2470	2500×2280×2650	2280×2900×2850	2280×2900×2950	2280×2900×2950
Packing dimension (Full-closure guard) (L × W × H)	mm	3000×2280×2470	3300×2280×2650	3700×2800×2870	3700×2890×2970	4700×2800×2970
Machine weight (Semi-closure guard)	kg	2600	3800	5000	5400	5200
Machine weight ((Full-closure guard)	kg	3400	4720	6400	6900	7500

Free Std Accessories

1. Semi cover(full cover is optional, extra money will be needed)
2. Cutting fluid circulation system
3. Auto lubrication system
4. Spindle air flow
5. Lamp
6. Pause lamp
7. Leveling adjusting screw and block
8. Clamping apparatus
Optional accessories:
1. Spindle from POSA spindle
2. Spindle speed: 8000rpm
3. Lead team lead screw made in Taiwan
4. Full closed safety guard
