X5750/X5057A China Ram Milling Machine for Sale

US$ 24,234 - 27,633 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Liaoning, China

Brand Name:

LFM

Long Life Machinery Import And Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian/Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Liaoning, China

Brand Name LFM

Model Number X5750/X5057A ram milling machine

Type Universal

CNC or Not Normal

Voltage 220V/380V/415V/440V/480V

Power(W) 3~11kW

Dimension(L*W*H) 2986x2260x2180mm

Weight 5/5.5 tons

Certification CE; ISO9001:2008; GB/T19001:2008

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

X5750/X5057A China ram milling machine

Main Features

Such ram milling machine has following features:

1. high strength HT-200 and high rigidity cast iron of bed;

2. guideways quenched and fine grinded;

3. x, y, z axis automatic feeding driven by servo motors;

4. ballscrew can be ordered specially;

5. CE Standard and CE Certificate;

6. DRO is available, too.

Main Technical Data

SPECIFICATIONS	UNIT	X5750 (UWF12B)	X5750A (UWF15B)
Table size	mm	500×1600	500×2000
T-slots(NO.×width×pitch)	mm	5×18×80	5×18×80
Table travel (X×Y×Z)	mm	1200×700×500	1500×700×500
Swivel angle of milling head	-	360°	360°
Spindle taper	-	ISO50	ISO50
Spindle speed range	r.p.m	(27) 30~2050	(27) 30~2050
Table feed (X/Y/Z)	mm/min	10~1000/10~1000/5~500	10~1000/10~1000/5~500
Table rapid speed	mm/min	2200/2200/1100	2200/2200/1100
Distance between spindle nose and table surface	mm	25~525	25~525
Distance from spindle center line to column	mm	55~755	55~755
Main motor power	kW	7.5	7.5
Feed motor	kW	AC servo motor X/Y:15NM; Z: 18NM	AC servo motor X/Y:15NM; Z: 18NM
Max load	kg	1800	1800
Overall size	mm	2475×2260×2180	2986×2260×2180
weight	kg	5000	5500
