X56/57 Series CE Ram Milling Machine Made in China

Long Life Machinery Import And Export Co., Ltd.

US$ 17,888 - 27,633 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Liaoning, China

Brand Name:

LFM

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Liaoning, China

Brand Name LFM

Model Number X5646 X5750 X5750A ram milling machine

Type Other, ram type

CNC or Not Normal

Voltage 220V/380V/415V/440V/480V

Power(W) 5.5/7.5kW

Dimension(L*W*H) depends

Weight 4/5/5.5 tons

Certification CE; ISO9001:2008; GB/T19001:2008

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

X56/57 ram milling machine Technical Data

Main Features

Such ram milling machine has following features:

1. high strength HT-200 and high rigidity cast iron of bed;

2. guideways quenched and fine grinded;

3. x, y, z axis automatic feeding driven by servo motors;

4. ballscrew can be ordered specially;

5. CE Standard and CE Certificate;

6. DRO is available, too.

Main Technical Data

SPECIFICATIONS	UNIT	X5646 (UWF10)	X5750 (UWF12B)	X5750A (UWF15B)
Table size	mm	460×1235	500×1600	500×2000
T-slots(NO.×width×pitch)	mm	5×18×80	5×18×80	5×18×80
Table travel (X×Y×Z)	mm	900×650×450	1200×700×500	1500×700×500
Swivel angle of milling head	-	360°	360°	360°
Spindle taper	-	ISO40	ISO50	ISO50
Spindle speed range	r.p.m	(27) 30~2050	(27) 30~2050	(27) 30~2050
Table feed(X/Y/Z)	mm/min	10~1000/10~1000/6~640	10~1000/10~1000/5~500	10~1000/10~1000/5~500
Table rapid speed		2200/2200/1100	2200/2200/1100	2200/2200/1100
Distance between spindle nose and table surface	mm	32~482	25~525	25~525
Distance from spindle center line to column	mm	47~697	55~755	55~755
Main motor power	kW	5.5	7.5	7.5
Feed motor	kW	AC servo motor X/Y:15NM; Z: 18NM	AC servo motor X/Y:15NM; Z: 18NM	AC servo motor X/Y:15NM; Z: 18NM
Max load	kg	800	1800	1800
Overall size	mm	1835×2362×2090	2475×2260×2180	2986×2260×2180
weight	kg	4000	5000	5500
