X6325B CE Vertical Turret Milling Machine for Sale

X6325B CE Vertical Turret Milling Machine for Sale thumbnail-1
X6325B CE Vertical Turret Milling Machine for Sale photo-1
US$ 5,074 - 33,971 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Liaoning, China
Brand Name:
LFM
Contact Supplier Request Quote Chat Now
Long Life Machinery Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Liaoning, China
Brand Name LFM
Model Number X6325B turret milling machine
Type Universal
CNC or Not Normal
Voltage 220V/380V/415V/440V/480V
Power(W) 3HP
Dimension(L*W*H) 1516x1550x2080mm
Weight 1323kgs
Certification CE; ISO9001:2008; GB/T19001:2008
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

X6325B vertical turret milling machine technical data

Main Usage
  • widely used for processing flat face, slope face, keyway, key groove, slot and drilling, reaming, boring;
Main Featurers
  • The milling head can turn 90°each side;
  • Ram can be turned 180° horizontally;
  • Spindle speed range is wide ranged and higher speed.
  • The spindle sleeve feeding can be set.
  • It is equipped with over load protection device.
  • Spindle sleeve and guide way is high frequency quenching. O
  • ur milling machine is good looking and practical.
Characters
  • Rectangular guide way on Y-and Z-axis is featured a good rigidity and stability.
  • The guide way on saddle is lined with TF wearable material.
Main Technical Data

Specifications

Unit

Parameter

Table size

mm

254×1270

254×1370

Longitudinal travel

mm

850

950

Cross travel

mm

400

Vertical travel

mm

420

T-slot no and size

mm

3×16

Ram travel

mm

470

Distance from spindle to table surface

mm

0~405

Spindle hole taper



Standard:R8

Optional: ISO30

ISO40

Spindletravel

mm

127

Spindlespeed

rpm

Standard: 16 gears:50Hz65~4500/60Hz

80~5440





Optional: Stepless speed 65~4500

Auto. quill feed

rpm

3 gears 0.04(0.0015)/0.08(0.003)/0.15(0.006)

Spindle motor

kW

2.25  3hp

Head swivel



90°

Head tilting

mm

45°

size of package

mm

1516×1550×2080

Weight

kg

1380
