Help CenterCL15x320 CE 8 Station Slant Bed Cnc Lathe Machine
Related Products
-
CE Slant Bed CNC Lathe With 12-station Turret Hot-sale DL30MUS$ 38,970 - 247,058MOQ: 1 Set -
DL20Mx1000 CE Slant Bed Cnc LatheUS$ 57,030 - 59,284MOQ: 1 Set
-
CE Slant Bed CNC Lathe Machinery Heavy-duty TypeUS$ 47,100 - 247,058MOQ: 1 Set
-
DL50x4000 CE Certified Inclined Bed Cnc Lathe for Sale Quality ChoiceUS$ 338,970 - 4,247,058MOQ: 1 Set
-
8-statioin Slant Bed CNC Lathe With CEUS$ 40,259 - 51,470MOQ: 1 Set
- such slant bed cnc lathe has following fetures:
- 60 ° inclined bed split,
- spindle Stepless Speed,
- 6″ hydraulic Solid chuck,
- 8-station hydraulic turret,
- Hydraulic tailstock,
- Lateral waste device,
- Full-closed protection,
- Linear guideways;
- Rigid cast-iron structure hardened (50-52HRC) and ground guarantee high precision and stability.
- Machine bed is made of heat stabilized cast-iron.
- A wide range of options and accessories allow the machine to be highly customized for very accurate and reliable machining.
- Kinds of CNC Controllers for your choice: FANUC, SIEMENS, FARGO, etc.
CL15 slant bed cnc lathe Specifications |
Unit |
CL15x320 8 station slant bed cnc lathe machine |
Swing over bed |
mm |
Φ400 |
Max turning length |
mm |
320 |
Max. turning diameter(Shafts) |
mm |
Φ160 |
Max. turning diameter(Discs) |
mm |
Φ200 |
Guide way type |
|
linear |
Chuck size |
|
6" |
Spindle nose |
|
ISO A2~5 |
Spindle speed |
rpm |
50~5000 |
Main spindle motor power(S6) |
kW |
5.5(7.5) |
Spindle bore diameter |
mm |
Φ46 |
Max bar diameter |
mm |
Φ32 |
Positioning accuracy |
mm |
(X) 0.016 (Z) 0.020 |
Repeat positioning accuracy |
mm |
(X) 0.007 (Z) 0.008 |
X-axis travel |
m/min |
120 |
Z-axis travel |
m/min |
340 |
X-axis rapid traverse |
mm |
15 |
Z-axis rapid traverse |
mm |
18 |
Turret: number of stations |
|
8 |
Tool shank size |
mm |
20×20 |
Tailstock quill diameter |
mm |
Φ60 |
Tailstock quill travel |
mm |
80 |
Tailstock taper |
MT |
3 |
Machine size: L×W×H |
mm |
3635x1460x1850 |
Net weight |
kg |
3500 |
1, Your inquiry will be replied in 24 hours;
2, Our manufacture/company has been a Gold supplier continuously in this Alibaba website for 7 years. And there is more industry technology experience for 24years with our manufactures;
3, To offer free spare parts and service within one year of warranty;
4, Technical Support Provide operation video for training;
5, Professional after-sales service team;
Call us at any time: +86 -15641121240/15641121140
Fax us:+86-411-84410129
Payment Term:
- 30% down payment, 70% by T/T before shipment;
- 100% LC at sight(optional and shall be discussed before placing order);
Minimum Order Quantity:
- 1 Set;
- ≥2 sets, there will be much discounts.
Warranty:
- Normally, 12 months for parts as of delivery of the machines;
Shipment:
- For machine itself, by sea or train(inland countries).
- For documents, by international express. eg DHL, TNT or EMS.
