Specifications
CE;45 Slant;
Swing over bed 440~1000(mm)
Max turning length 600~3000(mm)
Turret:hydraulic 12-station
CE Slant Bed CNC Lathe with 12-station Turret
For detailed information, to: export(at)
The new DL series of CNC slant bed lathes with rigid cast-iron structure hardened (50-52HRC) and ground guarantee high precision and stability. The machine bed is made of heat stabilized cast-iron.Varous configuration are available with spindles from ASA 5" to ASA 15",power up to 30kW and tuning length up to 3000mm,A wide range of options and accessories allow the machine to be highly customized for very accurate and reliable machining.
Item |
DL15 |
DL20 |
DL20M |
DL25M |
DL30M |
DL32M |
DL40 |
DL50 |
Swing over bed mm) |
¢450 |
¢460 |
¢460 |
¢520 |
¢625 |
¢680 |
¢800 |
¢1000 |
Center distance (mm) |
320 |
600/1000 |
600/1000 |
1000/1500 |
1000/1500 |
1000/2000 |
2000/2500/3000 |
2000/3000/4000 |
Max. turning diameter(Shafts/ Discs)(mm) |
¢250/300 |
¢260/380 |
¢260/380 |
¢310/500 |
¢310/600 |
¢400/630 |
¢550/750 |
¢800/1000 |
Guide way type |
linear |
linear |
linear |
box-type |
linear |
box-type |
box-type |
box-type |
Chuck size |
6" |
8" |
8" |
10" |
12" |
15" |
15" |
15" |
Spindle nose |
ISO A2-5 |
ISO A2-6 |
ISO A2-8 |
ISO A2-8 |
ISO A2-8 |
ISO A2-11 |
ISO A2-11 |
ISO A2-15 |
Spindle speed (rpm) |
50~5000 |
40~4000 |
45~4500 |
35~3500 |
30~3000 |
20~2000 |
20~2000 |
50~1200 |
Main spindle motor power(S6)(kW) |
5.5/(7.5) |
11(15) |
11(15) |
18.522 |
15(18.5) |
22(30) |
22(30) |
22(30) |
Spindle bore diameter (mm) |
¢70 |
¢70 |
¢76 |
¢88 |
¢88 |
¢100 |
¢100 |
¢100 |
X-axis travel (mm) |
150 |
220 |
265 |
260 |
325 |
375 |
375 |
500 |
Z-axis travel (mm) |
320 |
540/1000 |
700/1040 |
1100/1600 |
1110 |
1030/2030 |
2160/2660/3160 |
2160/3160/4060 |
X-axis rapid traverse(m/min) |
20 |
12 |
20 |
12 |
24 |
13 |
12 |
12 |
Z-axis rapid traverse(m/min) |
20 |
16 |
20 |
12 |
24 |
13 |
16 |
12 |
Positioning accuracy(mm) |
X 0.016 Z 0.020 |
X 0.016 Z 0.025 |
X0.010 Z0.012 |
X 0.016 Z 0.025 |
X 0.019 Z 0.032 |
X 0.019 Z0.032 |
X 0.019 Z 0.040 |
X 0.019 Z 0.040 |
Repeat positioning accuracy(mm) |
X 0.007 Z 0.008 |
X 0.007 Z 0.010 |
X 0.0040 Z 0.006 |
X 0.0070 Z 0.010 |
X 0.0010 Z 0.013 |
X 0.0010 Z 0.013 |
X 0.0012 Z 0.015 |
X 0.0012 Z 0.020 |
Turret: number of stations |
8 |
12 |
12 |
12 |
12 |
12 |
12 |
12 |
Tool size (mm) |
20×20 |
25×25 |
25×25 |
25×25 |
25×25 |
32×25 |
32×25 |
32×25 |
Tailstock quill diameter(mm) |
¢70 |
¢85 |
¢85 |
¢100 |
¢140 |
¢160 |
¢160 |
¢180 |
Tailstock quill travel(mm) |
80 |
100 |
139 |
139 |
150 |
180 |
180 |
180 |
Tailstock taper(MT) |
4 |
4 |
5 |
5 |
5 |
5 |
5 |
6 |
