CNC Sliding Guide Way Vertical Machining Center

Name: CNC Sliding Guide Way Vertical Machining Center
Brand: DALIAN
SKU: 102714861
Availability: InStock

Long Life Machinery Import And Export Co., Ltd.

US$ 45,132 - 108,060 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Vertical

Place of Origin:

Liaoning, China

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Vertical

Place of Origin Liaoning, China

Brand Name DALIAN

Model Number VDF1000 VDF1200 VDF1500 VDF1800

Certification CE Certificate

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

Box Way Vertical Machining Center

Main Features:

l With CE Certificate;

l National Inspection-free products

l Highly rigid and stable machine structure;

l High precision slide ways on three-axis;

l High speed, high-precision spindle;

l Fast and reliable tool changing mechanism,

l Cooling system;

l Multi-function CNC control system;

Item	VDF1000	VDF1200	VDF1500	VDF1800
Table(L×W)(mm)	1120×560	1220×620	1700×800	2000×800
T-slot(Numbers × Width × Distance) (b/t slots)	5×18×100	5×18×100	6×18×125
Table load Max(kg)	750	1200	2500
The distance from spindle center line to column guide way surface(mm)	629	660	850
The distance from spindle nose end face to table upper surface(mm)	135-735	90-765	200-962	180-942
X/Y/Z travel(mm)	1020/560/600	1200/600/675	1530/800/762	1850/800/762
X/Y/Z guide way type	box way	box way Y-axis 4 rails	box way Y-axis 4 rails
X/Y/Z rapid traverse speed(m/min)	24/24/18	20/20/18	15/15/12
Feedrate (mm/min)	1-10000	1-10000	1-6000
X/Y/Z servo motor power(Nm)	12/12/12	22/22/22	22/22/22
Spindle motor power(kW)	7.5/11	11/15	11/15 wide range motor
Spindle speed range(r/min)	60-8000	45-6000	45-6000
Spindle taper	#40(7/24)	#50(7/24)	#50(7/24)
Tool magazine capacity/Type	20/drum 24/swingarm	24/swing arm	24/swing arm
Tool adaptor type	BT40	BT50	BT50
Max. Tool weight(kg)	7	15	15
Max. Tool diameter/length(mm)	77/305 swing arm	127/305 swing arm	110/350swingarm
Time of tool change(T-T)(sec)	6-8/3	3.5	3.5
Air pressure requirement (mPa)	0.6	0.6	0.6
Power requirement (kW)	25	35	40
Overall dimension(L×W×H)	2820×2820×2477	2880×2815×2791	4300×3480×3120	5160×3480×3120
Net weight (kg)	8000	8500	14000	14500
