High Speed High Quality HDPE film blowing machine
Advantages:
It is used for blowing high
low pressure polyethylene,which has been widely used for producing laminating film,packing film,agricultural covering film,bag or film for textile and clothing and other packing material,the main motor adopts frequency control of motor speed to timprove the speed regulating stadility of main motor and save
electricity by 30%,the screw and material barrel adopt38 chrome-molybdenum aluminum which has been nitrogen treated and the traction frame adopts lifting type,no matter what size the film is big or small,lt can achieve the best effect of cooling.
Model |
SF-45 |
SF-55 |
SF-65 |
screw diameter |
Φ45 |
Φ55 |
Φ65 |
screw ratio L/D |
28:1 |
28:1 |
28:1 |
Suitable Material |
HDPE/LDPE |
||
main motor power |
11kw |
18.5kw |
30kw |
Max.extrusion output |
55kg/h |
70kg/h |
90kg/h |
range of die |
Φ60 Φ80 |
Φ100 Φ150 |
Φ120 Φ250 |
Film thickness |
0.009-0.05mm |
0.009-0.05mm |
0.009-0.05mm |
max folding width of film |
600mm |
800mm |
1000mm |
Average Power-consume |
18kw |
31kw |
45kw |
overall dimension |
3000×2800×4200 |
3500×3500×4800 |
4000×4000×6000 |
weight of machint |
3.5T |
4.0T |
4.5T |
Payment:T/T 30% with the order,70% before the shipment
Delivery time:30-40 days
Packing:By standard export packing.
Installation: If need our engineer go to your country to install, please repare the material and bulid machine firstly. Also buyer should take charge the tickets go and back, live, food and salary of our engineer.
Guarantee:One year, machine trouble is caused by nature not by human force from delivery time . Easily wear parts also is one year. after sale service for all life.
