quartz sand ball miller
1.Quartz Sand Ball Miller Introduction
- Quartz sand ball miller by feeding, discharging, rotary part, transmission part (reducer, small transmission gear, motor, electric control) and other major parts.
- Quartz sand ball miller lining and grinding ball with silica, alumina, rubber materials, in the process of grinding quartz, reduce the incorporation of impurities such as iron, guarantee the purity of quartz.
2.Quartz sand ball miller performance characteristics:
a. The wide scope of application, simple structure, easy maintenance.
b. The capacity is big, continuous operation.
c. The cylinder liner, grinding media can be used a variety of materials, corrosion resistance is strong, widely used.
d. Easy installation, debugging, easy to operate.
e. High production efficiency, low use cost.
3.quartz sand ball miller working principle picture
4.Quartz Sand Ball Miller Technical Data
| Type |
Shaft Rotation
Speed
(r/min) |
Ball Load (t) |
Feeding Size(mm) |
Discharging Size (mm) |
Capacity
(t/h)
|
Motor Power
(kw)
|
Weight(t) |
Φ900×1800 |
36 |
1.5 |
0-15 |
0.075-0.8 |
0.5-1.3 |
18.5 |
4.9 |
| Φ1200×2800 | 36 |
3.5 |
0-20 |
0.075-0.8 |
1.2-3.7 |
37 |
12.5 |
Φ1500×3500 |
29.7 |
7.5 | 0-25 | 0.075-0.8 |
3.3-8.8 |
75 |
16.5 |
Φ1830×3600 |
25.4 |
13 |
0-25 | 0.075-0.8 |
4-8 |
130 |
30 |
Φ2100×3600 |
23.7 |
18 |
0-25 | 0.075-0.8 |
4.5-33 |
180 |
37 |
Φ2400×3000 |
21 |
23 |
0-25 | 0.075-0.8 |
7-50 |
245 |
54 |
Φ2700×3600 |
20.7 |
10 |
≤25 |
0.075-0.8 |
12-75 |
400 |
86 |
Weilite are professional mining machine manufacturer. If you need our machines, please let me know your raw material size and capacity. Our professional engineer will help to recommend the most suitable type for your project. Hope we can cooperate with you.
5.Our Services For Quartz Sand Ball Miller
1)Pre-sale services: Enthusiasm
- We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.
2)Sale services: Servant
- Send technicians to the jobsite for guiding the installation and adjustment, training operators and finishing the check and accept together with you.
3)After-sale services: Faithfulness
- To establish long term friendship, we will regularly pay return visit to customers. Supplying technique, building design, instruction, installation and debugging for free.
4)We provide one-year warranty to make sure your machine runs consistently.
- We always offering lifelong services and provide spare parts for a long term,and repair main parts under right using for free in one years.
6.Company Introduction
We Zhengzhou Weilite Machinery Equipment Co., Ltd is a manufacturer and exporter of mining machinery, metallurgical equipment and building materials in China. Our main products are crusher, grinding mill, dryer, briquetting machine and so on. All of them are ISO9001:2000 confirmed. They are excellent quality and enjoy good reputation both in China and overseas. Welcome to visit and purchase from us!
Tel:+86 (0)371 86687769
Cell Phone:+86 15137145403
Contact Name:Ms. Ivy Zhang (sales manager)
Skype:ivyzhang2421
